Specifications
Model Number :
SW-305P
N.W. :
9.36kg
Brand Name :
Intuiit
Beam angle :
15°-30°
Type :
gobo projector
Supply Ability :
2000pcs/month
Lamp power :
100W
Warranty :
1 years
Delivery Time :
15-30days
Light source :
LED
MOQ :
negotiable
Packaging Details :
Cartons
Gobo :
7+ open white
Payment Terms :
L/C, T/T
Input voltage :
AC 100V- 240V
Certification :
CE
Place of Origin :
China
IP rated :
IP65
Dimension :
398*273*165MM
Description

SW-305P: 100W IP65 Gobo Projector – Auto-Focus Zoom Optics with 7+1 Rotatable Wheel

15°–30° Variable Zoom. Instant Auto-Focus. One All-Weather Projection Platform.

Key Specifications

Parameter Specification
Light Source 90W High-Output LED
Beam Angle 15° – 30° Motorized Zoom
Focus Rapid Auto-Focus
Gobo Wheel 7 + 1 Rotatable, Bi-Directional Indexable
Control DMX512 / RDM
IP Rating IP65
Series Options 90W / 200W / 400W

Core Advantages

Motorized 15°–30° Zoom with Auto-Focus. Adjust projection scale and coverage without manual intervention. The integrated auto-focus mechanism maintains razor-sharp image clarity across the full zoom range—critical for long-throw architectural installations where lens access is impractical.

7+1 Rotatable Gobo Wheel. Bi-directional, indexable wheel enables swift pattern changes and dynamic rotating effects. Combine static branding with motion-driven textures to create layered visual narratives from a single fixture.

Dynamic Effects Suite. Beyond static gobo display—deploy rotating patterns, strobe sequences, and motion effects to transform building facades and event spaces into immersive visual environments that evolve with the production.

IP65 Maintenance-Free Installation. Fully sealed against dust and high-pressure water jets. Engineered for permanent outdoor deployment across seasonal extremes, eliminating the service intervals that inflate total cost of ownership.

Scalable Lumen Architecture. The SW-305P series extends to 200W and 400W variants, enabling consistent optical quality across projects of any scale—from boutique storefronts to stadium-scale branding.

Applications

Outdoor Branding & Logo Projection · Architectural Facades · Event & Festival Decor · Theatrical Installations · Public Art · Seasonal Campaigns

Specification

Product Name 100W Outdoor Gobo projector
Item Number SW-305P
Product Measurement 398*273*165MM
Inner Packing Size 485*350*250MM
Packing Quantity 1pc/Carton
N.W. 9.36KG
Housing Material/Color Die casting Magnesium Alloy/Matt Black
Device Linking DMX in/out(3 pin),power in/out
Rotating gobo 7+1 CCT 9359K
Power Factor 1.0 Focus, prism
Input Current 1.211A @100V 0.526A @240V
Power line System European/American 9PCS @100V 22PCS @240V
Beam Angle(Optional) 15°-30°,25°, 55°
Data Protocol DMX512. RDM
