COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof
Specifications
Brand Name :
Highmight
Model Number :
COB-Z
Certification :
CE FCC RoHS
Place of Origin :
Guangdong, China
MOQ :
>=1 pieces
Price :
Customized price
Payment Terms :
T/T
Delivery Time :
7-35 work days
Packaging Details :
Flight case/wooden case/carton case packing
Name :
Small Pixel Pitch LED Panel
Color :
Full Color
Panel Size :
600mmx337.5mmx32.5mm
Media Available :
datasheet, Photo
Application :
Indoor
Brightness :
500-800 cd/㎡
Contrast Ratio :
≥5000:1
Lifespan (hours) :
≥100000H
HS Code :
8528591090
Resolution :
640x360
Material :
Die-casting Aluminum
maintenance :
Front Maintenance
Refresh rate :
1920/3840
Scan mode :
1/60 scan
LED chip :
MINI4in1
Maximum power(W/㎡) :
200-300W
Description

COB - Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof

Detailed product introduction document:Small Pitch COB-Z Series.pdf

Applicable scenarios:

1. studio
2. Business Center
3. Exhibition hall exhibition
4. stage
5. Tech Venues
6. Entertainment culture
7. Enterprise showroom

Features:

1. Ultra-thin 16:9 gold display ratio, easy to achieve 4K/8K broadcast HD;
2. With 125% of the NTSC color gamut of broadcast grade, it has excellent color expression and reduction;
3. It has the functions of dustproof, shockproof, anti-collision, moisture-proof, anti-oxidation, anti-static, etc;

Product Details

Models:COB-Z

MiniCOB small pitch Z series
Module model (mm) Z 0.62 Z 0.78 Z 0.93 Z 1.25 Z 1.56 Z 1.87
Module point spacing (mm) 0.62 0.78 0.9375 1.25 1.5625 1.875
Module Size (mm) 150x168.75 150x168.75 150x168.75 150x168.75 150x168.75 150x168.75
Module pixel 240x270 192x216 160x180 120x135 96x108 80x90
Packaging process Full flip COB Full flip COB Full flip COB Full flip COB Full flip COB Full flip COB
Module surface technology Matte Matte Matte Matte Matte Matte
Physical pixels (dot/㎡) 2560000 1638400 1137778 640000 409600 284444
Circuit scheme Common cathode circuit Common cathode circuit Common cathode circuit Common cathode circuit Common cathode circuit Common cathode circuit
Brightness (cd/㎡) 500-800 500-800 500-800 500-800 500-800 500-800
Refresh rate (Hz) 3840 3840 3840 3840 3840 3840
Color temperature (K) 9000 9000 9000 9000 9000 9000
surface hardness 4H 4H 4H 4H 4H 4H
Box size (mm) 600x337.5 600x337.5 600x337.5 600x337.5 600x337.5 600x337.5
Cabinet resolution (dots) 960x540 768x432 640x360 480x270 384x216 320x180
Box weight(kg) 8kg 8kg 8kg 8kg 8kg 8kg
Service life ≥100,000 hours
Pixel composition RGB 3-in-1
Grayscale 14bit
Maximum power (W/㎡) 600-800W
Average power (W/㎡) 400-600W
Eliminate ghosting Equipment
input voltage AC100～240V 50/60HZ
Module input voltage DC4.7～5V±0.2V
Environment Temperature -10～40℃ Humidity 10％-90％

Application:

COB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproofCOB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproofCOB-Z Series Small Pixel Pitch LED Screen Ultra-thin dustproof shockproof

FAQ:

Q1: What is the maintenance method for the product

A : front and rear maintenance

Q2: Can I have a sample order for led screen?

A : Yes, we welcome sample order to test and check quality.
