Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail
Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail
Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail
Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail
Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail
Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail
Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail
Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail
Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail
Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail
Specifications
Brand Name :
BAKO VISION
Model Number :
BP Series
Certification :
CE RoHS EMC UL FCC
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, D/P, D/A, MoneyGram
Supply Ability :
8,000 sets per month
Delivery Time :
15-20 working days
Packaging Details :
Flight Case
LED type :
P2.5
Screen size :
571*1897*33mm
Maintenance Way :
Front Service
Driving Method :
1/27 Scan
Brightness :
800~1,000nits
IP rating（front/rear） :
IP43
Viewing Angle :
160°(horz.)/ 140°(vert.)
Average Power Consumption :
100 W/Set
Max. Power Consumption :
390 W/Set
Warranty :
2 Years
Description

Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail (BP.pdf)

Indoor LED Poster Features

1. Flat and Slim, only 33mm in thickness - Convenient in transporting & installing, saving labor cost and installation space, suitable for flow shows.

2. Smart control, friendly for new user - WiFi/USB/Mobile App.

Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail

3. Tool free assemble - Point-to-point, wheels base to move easily.

Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail

4. Front access module with detailed control structure.

Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail

5. Multi-screen cascade - Free splicing technology.

Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail

6. Multiple installation ways

Indoor LED Poster Panel P2.5 Mirror LED Screen for Shopping Mall Advertising Retail

Advertising LED Signage Parameters
Pixel Pitch 1.875mm 2.5mm 2.5mm Pro 3.0mm
Pixel Configuration SMD 1515 SMD 2121 SMD 2121 SMD 2121
Pixel Density 279,936pixels/m² 169,344pixels/m² 157,464pixels/m² 110,889pixels/m²
Module Dimention(mm) 160 × 160 320 × 160 280 × 210 192 × 192
Whole Set Dimention(mm) 640 × 1920 × 35 640 × 1920 × 35 571× 1897 × 33 576 × 1920 × 35
NO.of Modules Per Panel 4 × 12 2 × 12 2 × 9 3 × 10
Resolution of Module 84 x 84 64× 64 108× 81 64 × 64
Resolution of Whole Set 336 × 1,010 256 × 768 216 × 729 192× 640
Panel Material Aluminum / Steel
Cabinet Weight 32 kg 32 kg 28 kg 32 kg
Gray Level 16 bit(281 trillion colors)
Average Power Consumption 250W/Set 200W/Set 100 W/ Set 200 W/ Set
Max Power Consumption 750W/Set 600W/Set 390 W / Set 600 W / Set
Driving Method 1/32 Scan 1/32 Scan 1/27 Scan 1/32 Scan
Brightness >1,000 nits >1,000 nits >1,000/3500 nits >1,000 nits
Refresh Rate ≥2,880 Hz ≥2,880 Hz ≥3,840 Hz ≥2,880 Hz
Viewing Angle(V/H) 160°/ 140°
Frame Rate 60 fps
Operating Temp/Humidity -10ºC~60ºC / 10%~60%
Storage Temp/Humidity -30ºC~60ºC / 10%~60%
IP Rating (Front/Rear) IP40
Expected Lifetime 100,000 Hrs
