Indoor IP40 commercial LED display screen With Nationstar LEDs
Indoor IP40 commercial LED display screen With Nationstar LEDs
Indoor IP40 commercial LED display screen With Nationstar LEDs
Indoor IP40 commercial LED display screen With Nationstar LEDs
Indoor IP40 commercial LED display screen With Nationstar LEDs
Indoor IP40 commercial LED display screen With Nationstar LEDs
Indoor IP40 commercial LED display screen With Nationstar LEDs
Indoor IP40 commercial LED display screen With Nationstar LEDs
Specifications
Brand Name :
BAKO VISION
Model Number :
P2.97
Certification :
CE,ETL,RoHS,FCC,3C,UL
Place of Origin :
Shenzhen,China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000m²/month
Delivery Time :
20-25 work days
Packaging Details :
Flight Case/Road Case
Pixel Pitch :
2.97mm
Pixel Density :
112,896pixels/m2
Cabinet Dimension :
500x500mm
Cabinet Material :
die casting aluminum
Ingress Protection(front/rear) :
IP40
MTBF :
≥1000hrs
Pixel Failure :
<0.0003
Description

Indoor IP40 Commercial LED Display Screen With Nationstar LEDs

Light weight P2.97 indoor led video panel with Nationstar leds

P2.97 indoor led video panel Specs

BIR-II-2
Physical Pitch(mm)2.97mm
Pixel ConfigurationSMD2121
Pixel Density112,896 pixels/sqm
Module Dimensions (W × H) (mm)250x250
Panel Dimensions (mm)500x500x80/500x1000x80
No. of Modules Per Panel (W × H)2x2/2x4
Physical Resolution of Module (W x H)84x84
Physical Resolution of Panel (W x H)168x168/168x336
Panel MaterialDie-casting Aluminum
Single Cabinet Weight8/14 kg / panel
Gray Scale16 bit
Colours281 trillion
Contrast Ratio4,000:1
Average Power Consumption400 W / ㎡
Max Power Consumption800 W / ㎡
Operating Temp/Humidity-10°-60℃/10%-60%
Storage Temp/Humidity-30°-60℃/10%-60%
Refresh Rate>1,920 Hz
Brightness≥1,200nits
Horizontal Viewing Angle160°
Vertical Viewing Angle140°
Expected Lifetime100,000 Hrs



P2.97 indoor led video panel features:
1. Rental Die-Casting Aluminum structure
2. Lightweight
3. Seamless Splicing
4. Excellent thermal management
5. Quick lock system, easy installation
6. Wide viewing angle
7. Working status indicator
8. The pitch 8mm led rental display with High-performance aluminum alloy frame with the weight only
10kg, which can save transportation cost and reduce labor intensity effectively.
9. Using quick rim lock to connect left-right and up-down cabinets, needs only 10s to install one cabinet,
very quick and easy for installing
10. Nanotechnology applied in the module, the protection rate can reach IP65.
11. Using the design of removable dowel pin, so a single cabinet can be taken out from the whole screen to have a repairment.

P2.97 indoor led video panel details:

1. Front access module makes easy maintenance service;
Indoor IP40 commercial LED display screen With Nationstar LEDs
2. Detachabel power box design;
Indoor IP40 commercial LED display screen With Nationstar LEDs
3. Corner protecor protects leds in all corners;
Indoor IP40 commercial LED display screen With Nationstar LEDs
