Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21
Specifications
Brand Name :
Bako Vision
Model Number :
BIR-III
Certification :
CCC,CE,ETL,RoHS
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
8000sqms/month
Delivery Time :
15days
Packaging Details :
Flight case,Plywooden case
Cabinet Material :
Die-casting Aluminum
Panel Dimention :
500*500/500*1000
Brightness :
>1,200nits
Contrast Ratio :
4000:1
Tube chip color :
Full Color
Pixel configuration :
1R1G1B
Description

Tools Free Installation Indoor Advertising Led Display Screen High Brightness

BIR-III-2X BIR-III-2 BIR-III-3 BIR-III-4
Physical Pitch 2.6mm 2.97mm 3.91mm 4.81mm
Pixel Configuration SMD2121 SMD2121 SMD2121 SMD2121
Pixel Density 147,456 pixels/㎡ 112,896 pixels/㎡ 65,536 pixels/㎡ 43,264pixels/㎡
Module Dimensions (W*H)(mm) 250*250 250*250 250*250 250*250
Panel Dimensions(mm) 500*500*80/500*1000*80 500*500*80/500*1000*80 500*500*80/500*1000*80 500*500*80/500*1000*80
Physical Resolution of Module(W*H) 96*96 84*84 64*64 52*52
Physical Resolution of Panel(W*H) 192*192/192*384 168*168/168*336 128*128/128*256 104*104/104*208
Panel Material Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum Die-casting Aluminum
Single Cabinet Weight 8/14 kg/panel 8/14kg/panel 8/14kg/panel 8/14kg/panel
Processing 16 bit 16 bit 16 bit 16 bit
Colours 281 trillion 281 trillion 281 trillion 281 trillion
Contrast Ratio 4,000:1 4,000:1 4,000:1 4,000:1
Average Power Consumption 64/128W/panel 64/128W/panel 64/128W/panel 64/128W/panel
Max Power Consumption 192/384W/panel 192/384W/panel 192/384W/panel 192/384W/panel
Refresh Rate >1,920Hz >1,920Hz >1,920Hz >1,920Hz
Brightness >1,200nits >1,200nits >1,200nits >1,200nits
Horizontal Viewing Angle 160° 160° 160° 160°
Vertical Viewing Angle 140° 140° 140° 140°
Max Staking 20/10 20/10 20/10 20/10
Max Hanging 20/10 20/10 20/10 20/10
Servicing Front/Rear Front/Rear Front/Rear Front/Rear
IP Rating (Front/Rear) IP40/IP21 IP40/IP21 IP40/IP21 IP40/IP21

Product Features

User Friendly and Fast Installation

Truss hanging and ground support both available

Fast lock and handle designed user friendly

Front and rear access

Tools free installation

Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21

Unsupassed Color Uniformity

→Unique color calibration precess

→Tight bin selection for LED wavelength

→Deep black levels,contrat ratio 4000:1

Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21

Slim,Light Weight and Quiet

500mm*500mm or 500mm*1000mm

80mm thickness

1 person job

Fanless design

Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21

Smart Concave and Convex

Both 500mm*500mm and 500mm*1000mm cabinets are arc-ble

0°-10° concave and convex degree

Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21

Advertising Led Display Full Color Indoor Rental LED Display Die Casing Aluminum Cabinet IP40 IP21

How to measure brightness?

Nit is a unit to measure luminance over a square meter. It is also well-known as meter-lamberts.
NIT = meter-lamberts = candela per square meter (cd/m2)

Why does brightness matter?
At night, generally speaking, LED displays are always readable and working fine.

How to make a good choice between the flight case and wooden case?

Flight case is usually used for the rental LED display, which makes the transportation more convenient and protect the LED display better.

Wooden case is only for one time using transportation, such as the fixed installation LED display, wooden case is the best way for packing since the low cost and at the same time it can also ensure the safety of the LED display.

If your LED display screen system is for the rental use, please choose the flight case.

What is best viewing distance? How to calculate the best viewing distance of the LED display?

Best viewing distance refers to the distance between the LED Display and its viewers, where the people can see a whole and clear picture of the image on the LED display.

There’s 2 ways to calculate the best viewing distance: one is by the pixel pitch, one is by the diagonal.
