Specifications
Contrast ratio :
4000:1
IP rating :
IP65/IP54
Refresh Rate :
>1920Hz
Panel Material :
Die-casting Aluminum
Servicing :
Front/rear
Expected lifetime :
100000 hours
Panel Size :
500x500x80mm
Brightness :
>6000nits
Brand Name :
BAKO VISION
Model Number :
BOR-III
Certification :
CE,CCC,FCC,ETL,EMC
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
6000sqm/month
Delivery Time :
15-25 Days
Packaging Details :
Flight case or plywood case
Description

Advertising Curved Outdoor Rental LED Display High Definition With 6000 Nits

Specifications:

BOR-III-3 BOR-III-4 BOR-III-5 BOR-III-6
Physical Pitch 3.91mm 4.81 mm 5.95mm 6.25 mm
Pixel Configuration SMD 1921 SMD 2727 SMD 2727 SMD 2727
Pixel Density

65536 pixels/m²

43264 pixels/m²

28224 pixels/m²

25600 pixels/m²
Module Dimensions (W × H) (mm) 250 × 250 250 × 250 250 × 250 250 × 250
Panel Dimensions (mm)

500 × 500 ×80

500 × 1000 × 80

500 × 500 ×80

500 × 1000 × 80

500 × 500 × 80

500 × 1000 × 80

500 × 500 ×80

500 × 1000 × 80
NO .of Modules Per Panel (W × H) 2 × 2/2×4 2 × 2 /2×4 2 × 2/2×4 2 × 2/2×4
Physical Resolution of Module (W × H) 64×64 52×52 42×42 40×40
Physical Resolution of Panel (W × H) 128×128/128×256 104×104/104×208 84×84/84×168 80×80/80×160
Panel Material Die-Casting Aluminum Die-Casting Aluminum Die-Casting Aluminum Die-Casting Aluminum
Single Cabinet Weight 9/ 15 kg/panel 9/ 15 kg/panel 9/ 15 kg/panel 9/ 15 kg/panel
Processing 16 bit 16 bit 16 bit 16 bit
Colors 281 trillion 281 trillion 281 trillion 281 trillion
Contrast Ratio 4,000: 1 4,000: 1 4,000: 1 4,000: 1
Average Power Consumption 75 /150 W/panel 75 /150 W/panel 75 /150 W/panel 75 /150 W/panel
Max Power Consumption 225 /550 W/panel 225 /550 W/panel 225 /550 W/panel 225 /550 W/panel
Operating Temp/Humidity -20℃ - 60℃ / 10% - 60% -20℃ - 60℃ / 10% - 60% -20℃ - 60℃ / 10% - 60% -20℃ - 60℃ / 10% - 60%
Storage Temp/Humidity -30℃ - 60℃ / 10% - 60% -30℃ - 60℃ / 10% - 60% -30℃ - 60℃ / 10% - 60% -30℃ - 60℃ / 10% - 60%
Refresh Rate ＞1,920 Hz ＞1,920 Hz ＞1,920 Hz ＞1,920 Hz
Brightness ≥6000 nits ≥6000 nits ≥6000 nits ≥6000 nits
Horizontal Viewing Angle 160° 160° 160° 160°
Vertical Viewing angle 140° 140° 140° 140°
Expected Lifetime 100, 000 Hrs 100, 000 Hrs 100, 000 Hrs 100, 000 Hrs
Max Stacking 20/10 20/10 20/10 20/10
Max Hanging 20/10 20/10 20/10 20/10
Servicing Front / Rear Front / Rear Front / Rear Front / Rear
IP Rating (Front/Rear) IP 65/ IP 54 IP 65/ IP 54

IP 65/ IP 54

 IP 65/ IP 54
Certification

CCC, CE,

ETL, RoHS

CCC,

CE, ETL, RoHS

CCC,

CE, ETL, RoHS

CCC, CE,

ETL, RoHS

Unsurpassed Color Uniformity

● The Unique color calibration process

● Tight bin selection for LED wavelength

● Deep black levels, contrast ratio 4000:1

Advertising Curved Outdoor Led Display Board , High Definition Led Public Display 6000 Nits

Fast Installation and Easy Maintenance
→ Truss hanging and ground support both available
→ Cable-less between modules
→ Front and rear access
→ Tools free installation

Advertising Curved Outdoor Led Display Board , High Definition Led Public Display 6000 Nits

Slim, Light Weight and Quiet
→500mm×500mm or 500mm×1000mm options
→ 80mm thickness
→ Fanless design

Advertising Curved Outdoor Led Display Board , High Definition Led Public Display 6000 Nits

Smart Concave and Convex

● Both 500mmx500mm and 500mmx1000mm cabinets are

arc-able

● 0°-10° concave and convex degree

Advertising Curved Outdoor Led Display Board , High Definition Led Public Display 6000 Nits

About us:

LED Vision Technology Limited  , started in Shenzhen in 2005, a world-class manufacturer of technologically advanced LED displays, focusing on professional customers among domestic and overseas markets. BAKOVISION is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.

BAKO VISION main markets are among America, Europe, the Middle East, and Asia, all of our products are certificated by RoHS, CCC, CE, FCC, ETL, UL. Standing firmly by quality, winning firmly by proficient, in the past years of development, BAKO VISION continuous growth and brand positioning are all relied on the long term partnership with variety channel customers over 120+ countries.

Advertising Curved Outdoor Led Display Board , High Definition Led Public Display 6000 Nits

Advertising Curved Outdoor Led Display Board , High Definition Led Public Display 6000 Nits

Advertising Curved Outdoor Led Display Board , High Definition Led Public Display 6000 Nits

FAQ:

Q1. Are you trading company or manufacturer?

A: We are a professional led screen manufacturer.

Q2. What's your payment term?

A: T/T, Western Union L/C

Q3. Do you provide samples ? is it free or extra?

A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

Q4. How about your delivery time?

A: Generally, the sample needs 5-7 days, 15-25 days for batch order

Q5. How do you ship the goods and how long does it take to arrive?

A: We usually ship goods by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Air Freight and sea shipping are also optional.

Q6. Do you offer a guarantee for the products?

A: Yes, we offer 2 years warranty for our products

Q7: How can I get technical support?

A: We will train in our factory and send video for showing. The training includes system use, system maintenance, and equipment protection.
