Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations
Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations
Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations
Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations
Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations
Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations
Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations
Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations
Specifications
Brand Name :
BAKO
Model Number :
BS
Certification :
CE, FCC, RoHS
Place of Origin :
CHINA
MOQ :
1m²
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
8000 m²/month
Delivery Time :
20 days
Packaging Details :
Wooden Case/Flight Case
Pixel Configuration :
SMD2121/SMD3528
Tube Chip Color :
Full Color
Weight :
8.2kg/m²
Brightness :
>1000 nits
Servicing :
Front
Expected Lifetime :
100,000Hrs
Description

Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations

Feature

Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations

Light weight: Only 8.2kg/m², shipping cost and installation cost saving.

Low energy: Average power consumption 9W

Slim: 5mm tickness, space efficiency

Fanless design: Make very silent but have a good dissipation

Parameter

Physical Pitch 2.5mm 3mm 4mm 6.66mm
Pixel Configuration SMD2121 SMD2121 SMD2121 SMD3528
Pixel Density 160,000 pixels/m²

111,111

pixels/m²

62,500

pixels/m²

22,545

pixels/m²
Module Dimensions(W*H)(mm) 240*120 240*120 240*120 320*160
Panel Dimensions(mm) Customized Customized Customized Customized
Physical Resolution of Module(W*H) 96*48 80*40 60*30 48*24
Weight 8.2kg/m² 8.2kg/m² 8.2kg/m² 8.2kg/m²
Colors 281 trillion 281 trillion 281 trillion 281 trillion
Processing 16 bit 16 bit 16 bit 16 bit
Contrast Ratio 4000:1 4000:1 4000:1 4000:1
IP Rating IP40 IP40 IP40 IP40
Horizontal/Vertical Viewing Angle 160°/140° 160°/140° 160°/140° 160°/140°
Expected Lifetime 100,000Hrs 100,000 Hrs 100,000 Hrs 100,000 Hrs
Operating Temp/Humidity

-20℃-60℃/

10%-90%

-20℃-60℃/

10%-90%

-20℃-60℃/

10%-90%

-20℃-60℃/

10%-90%
Storage Temp/Humidity

-40℃-80℃/

10%-90%

-40℃-80℃/

10%-90%

-40℃-80℃/

10%-90%

-40℃-80℃/

10%-90%
Servicing Front Front Front Front
Driving Method 1/40 1/40 1/8 1/8
Average Power Consumption 9W 9W 9W 9W
Max Power Consumption 12w 12w 12w 12w

About our Product

Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations

● Durable soft rubber module, anti-static electricity

● Soft PCB and rubber material

● Integrated SMD, IC, Circuit for easy maintenance and heat dissipation

● Magnetic connection for easy maintenance

Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations

● For Any Creative Shape and Size, For Unique

● Convex, Concave or Twisted Available Module

● Flexible Rubber Module, Creative Solutions

Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations

Our company

Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005, a world class manufacturer of technologically advanced LED displays, focusing on high end professional customers among domestic and overseas markets. BAKOVISION is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.

Soft Ribbon Rubber Flexible LED Display For Any Convex, Concave Or Twisted Installations

Our service:

1.Your inquiry related to our products or prices will be replied in 24hrs.
2.Well-trained and experienced staffs to answer all your enquires in fluent English .
3.OEM&ODM, any your customized screen we can help you to design and put into product.
4.Distributoer ship are offered for your unique design and some our current models .
5.Protection of your sales area, ideas of design and all your private information .
