Outdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High Resolution
Outdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High Resolution
Outdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High Resolution
Outdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High Resolution
Outdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High Resolution
Outdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High Resolution
Specifications
Brand Name :
Bakovision
Model Number :
BOF Series
Certification :
CE ETL FCC CCC
Place of Origin :
China
MOQ :
1㎡
Price :
$320/m2
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10,000 sqm/month
Delivery Time :
15-25 days
Packaging Details :
Wooden case or flight case
LEDs :
Nationstar
Pannel Material :
Steel
Servicing :
Front/Rear
Viewing Angle :
160°/140°
Refresh Rate :
＞1920Hz
Contrast Ratio :
2000:1
Brightness :
＞6500nits
IP Rating(Front/Rear) :
IP65
Description

Waterproof IP65 P8mm P10mm Front Service Outdoor Fixed LED Billboard Display Screen for Advertising

Features and Advantages:

Smart Cabinet Design

  • IP65 Ingress rate for extreme weather protection
  • Cold rolled steel with extra powder coating for anti-rust
  • The Resolution can be adjusted by changing modules directly without moving
  • Side handle convienent design for easy installation
  • Outdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High Resolution

High Visibility

  • Brighter even when in sunny days
  • High color uniformity and consistence
  • High definition and contrast

High Clarity SMD Technology

  • Closer viewing distance
  • Wider viewing angle
  • Front or rear serviceable


Specification

BOF-8 BOF-10
Physical Pitch 8mm 10mm
Pixel Configuration SMD3535 SMD3535
Pixel Density 15,625 pixels/Sqm 10,000 pixels/Sqm
Module Dimensions(W x H) (mm) 256 x 256 320 x 320
Panel Dimensions (mm) 1280 x 768 x 150 1280 x 960 x 150
NO. of Modules Per Panel (W x H) 5 x 3 4 x 3
Physical Resolution of Module (W x H) 32 x 32 32 x 32
Physical Resolution of Panel (W x H) 160 x 96 128 x 96
Panel Material Steal / Aluminum Steal / Aluminum
Weight (kg/Sqm) 65 / 45 65 / 45
Processing 16bit 16bit
Colours 281 trillion 281 trillion
Contrast Ratio 2,000 : 1 2,000 : 1
Average Power Consumption 360 W /panel 360 W /panel
Max Power Consumption 900 W /panel 900 W /panel
Brightness >6,500 nits >6,500 nits
Refresh Rate >1,920 Hz >1,920 Hz
Vertical Viewing Angle 160° 160°
Horizontal Viewing Angle 140° 140°
Expected Lifetime 100,000 Hrs 100,000 Hrs
Servicing Front / Rear Front / Rear
IP Rating (Front/Rear) IP 65 / IP 54 IP 65 / IP 54
Operating Temp/Humidity -20ºC - 50ºC / 10ºC - 90ºC -20ºC - 50ºC / 10ºC - 90ºC
Storage Temp/Humidity -20ºC - 50ºC / 10ºC - 90ºC -20ºC - 50ºC / 10ºC - 90ºC



Outdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High ResolutionOutdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High ResolutionOutdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High ResolutionOutdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High ResolutionOutdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High ResolutionOutdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High ResolutionOutdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High ResolutionOutdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High ResolutionOutdoor Fixed Billboard LED Display P8mm P10mm Waterproof With High Resolution

1. Are you trading company or manufacturer?
We are a professional led screen manufacturer located in Shenzhen since 2005.

2. How to payment?
We accept the L/C, T/T.

3. What is the packing method?
We usually use plywood case or flight case.

4. How about the delivery time?
We will ship within 15-25 working days after you placed the order, but the specific delivered time will be affected by the shipping company and shipping details.

5. Do you provide samples ? Is it free or extra?
We provide samples if you need, but the customers have to pay the sample cost and the courier cost.

6. How do you ship the goods?
We usually ship by DHL, UPS, FedEx or TNT. In addition, Airline and sea shipping also optional.

Our services
Pre-producing

  • Get complete requirements of clients.
  • To do a thorough analysis.
  • Offer a most reasonable and scientific solution.
  • Customized design.

In producing

  • Producing progress updating for clients.
  • Particular installation CAD and design diagram for clients.

After service

  • 2 years free maintenance.
  • 7 days a week, 24 hours a day for 5 years on-line service for any technical support for any customers.
  • Free training for customers in factory.
  • Arrange engineer go to your place to support installation.
