Specifications
Brand Name :
Bako Vision
Model Number :
BD Series
Certification :
CCC, CE, EMC, FCC, RoSH, ISO9001
Place of Origin :
China
MOQ :
1 per square meter
Price :
$650 - $905 per square meter
Payment Terms :
T/T, L/C, D/P, Western Union, Paypal
Supply Ability :
20,000 sqm/month
Delivery Time :
15-20 working days
Packaging Details :
Flight case / Plywood case
Product Name :
Stage Rental LED Display
Pitch Pixel :
P3.91, P5.2, P6.25, P8.928
Module Dimension (WxH) :
250*250mm
Cabinet Dimension (WxH) :
500*1000mm
Cabinet Material :
Aluminum
Cabinet Weight :
25kg/pc
Brightness :
2000 nits - 4500 nits
Maintenance Way :
Front
IP Rating :
IP65/IP54
Life span :
100,000 Hours
Warranty :
2-5 Years
Description

Rental LED Stage Screen Interactive LED Panel Dance Floor Video Tile Display

BD Series (BD.pdf)

Dance Floor LED Display

Specifications
Pixel Pitch: 3.91mm / 5.2mm / 6.25mm / 8.928mm
Bearing Capacity: 1.8 tons per square meter
Refresh Rate: > 1920Hz
Key Point: It is attracting more traffics, have fun with it

Key Features

· Same Operation Way With the Regular LED Screen.

· Easy To Install And Maintenance.

· Very Durable, is Able to Support The SUV Car On it.

· Interactive And Non-interactive Design Accepted.

· High Brightness and Good Visual Display Performance.

Rental LED Stage Screen Interactive LED Panel Dance Floor Video Tile Display


Rental Stage LED Screens Parameters

BD-3 BD-5 BD-6 BD-8
Physical Pitch 3.91 mm 5.2 mm 6.25 mm 8.928 mm
Pixel Configuration SMD 1921 SMD 1921 SMD 2727 SMD 3535
Pixel Density 65,536 pixels/m² 36,864 pixels/m² 25,600 pixels/m² 25,600 pixels/m²
Module Dimensions (W × H) (mm) 250 × 250
Panel Dimensions (mm) 500 × 1000
Physical Resolution of Module (W × H) 64 x 64 48 x 48 40 x 40 28 x 28
Physical Resolution of Panel (W × H) 128 x 256 96 x 192 80 x 160 56 x 112
Panel Material Aluminum
Single Cabinet Weight 20 kg/panel 25 kg/panel 24 kg/panel 25 kg/panel
ray Scale 16 bit
Colours 281 trillion
Contrast Ratio 4,000 : 1
Average Power Consumption 300 W / m²
Max Power Consumption 880 W / m² 880 W / m² 600 W / m² 600 W / m²
Operating Temp/Humidity -10℃-60℃ / 10%-60%
Storage Temp/Humidity -30℃-60℃ / 10%-60%
Refresh Rate >1,920 Hz
Brightness 2,500 nits 2,000 nits 4,500 nits 4,500 nits
Horizontal Viewing Angle 160°
Vertical Viewing Angle 140°
Expected Lifetime 100, 000 Hrs
Best Viewing Distance 4m 5m 6m 9m
Scan Method 1 / 16 Scan 1 / 6 Scan 1 / 5 Scan 1 / 3 Scan
Maintenance Way Front
IP Rating IP 65

Where can we use the floor LED screen ? What benefits can it bring ?

Rental LED Stage Screen Interactive LED Panel Dance Floor Video Tile Display

As long as you need to attract traffic, the floor LED screen will become your best weapon. For example, shopping malls, exhibitions, amusement parks, bars, stages, urban greening, landmark buildings, corporate logos, square markets, automobile 4S shop.

1. Increase in traffic - It can bring customers new and magical fun experiences, it can attract customers to your event venue.

2. Increase the profits of the surrounding stores - It can indirectly increase the purchase amount of the store, increase the local business value of the place, and attract more brands to stay.

3. Stimulate the audience’s senses and enhance the viewing experience - When your competitors are still using the LED screens, considerable posters to catch the customers, you are already making the entire stage performance into their body and blood, which can allow you to compete against to have a better stage effect.

4. Increase the fun of entertainment

5. In the place of public welfare activities, it is like a city landmark

Interactive LED Panel Cases

Rental LED Stage Screen Interactive LED Panel Dance Floor Video Tile Display

About Bako Vision

Rental LED Stage Screen Interactive LED Panel Dance Floor Video Tile Display

  • Over 10 Years Experience on LED Display Screen Manufacturing in China.
  • 3 Years High Quality Warranty Provided.
  • Global Quality Standard with CE, EMC, ROHS, ETL, UL, FCC, ISO9001 Certificated.
  • Overseas Customer in 120+ Countries in The World.
  • Full Capable to Provide the Tailor Work of OEM, ODM.

FAQ:
Q1. Are you trading company or manufacturer?
A: We are a professional led screen manufacturer.
Q2. What is your terms of payment?
A: T/T or Western Union 30% as deposit, and 70% before delivery. Will show you the Professional Quality Control Photos before you pay the balance. Then you could see everything by your eyes before the shipment.
Q3. How about your delivery time?
A: Generally, sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than.
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty for your products.
Q6: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Q7: How can I get technology support?
A:1. We could give you the free training in our factory, which include system use, system maintenance and equipment protection ect.

2. We could teach you by remotely if anything not clear.
