80*80 Pixels P8 Led Screen Stage Backdrop , High Definition Led Display Ultra Slim
80*80 Pixels P8 Led Screen Stage Backdrop , High Definition Led Display Ultra Slim
80*80 Pixels P8 Led Screen Stage Backdrop , High Definition Led Display Ultra Slim
80*80 Pixels P8 Led Screen Stage Backdrop , High Definition Led Display Ultra Slim
80*80 Pixels P8 Led Screen Stage Backdrop , High Definition Led Display Ultra Slim
80*80 Pixels P8 Led Screen Stage Backdrop , High Definition Led Display Ultra Slim
Specifications
Brand Name :
BAKO VISION
Model Number :
ORB-8
Certification :
CE,ETL,RoHS,FCC,3C,UL
Place of Origin :
Shenzhen,China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
D/A, D/P, L/C, T/T, Western Union, Paypal,MoneyGram,MasterCard,Visa,Credit Card
Supply Ability :
10000m²/month
Delivery Time :
20-25 work days
Packaging Details :
Flight Case/Road Case
Pixel Pitch :
8mm
Pixel Density :
15625 pixels/m2
LED Type :
SMD3535
Cabinet Resolution :
80*80 pixels
Ingress Protection(front/rear) :
IP65/IP54
Driving Method :
1/5 Scan
Gray Scale :
16bit
Life Span :
≥100000hrs
Description

P8 Outdoor Stage Rental LED Display Ultra Slim and Lightweight High Refresh Rate

Key Feature

• Ultra slim and lightweight
• Rental die-casting aluminum structure
• Seamless splicing
• Quick lock system, easy installation
• High refresh rate and high contrast
• Wide viewing angle
• Working status indicator available

Specification

Model ORB-8
Pixel Pitch 8mm
Pixel Density 15625 pixels/m2
LED Type SMD3535
LED Configuration 1R1G1B
Cabinet Dimension 640mmx640mm
Cabinet Resolution 80*80pixels
Cabinet Weight 13kg
Cabinet Material die casting aluminum
Ingress Protection(front/rear) IP65/IP54
Brightness >6500nits
Viewing Angle(H/V) 140°/140°
Driving Method 1/5 Scan
Frame Refresh ≥ 60Hz
Data Refresh Rate >1500Hz
Gray Scale 16bit
Power Consumption(avg.) 275w/m2
Input Voltage AC 110/220±10%, 50~60Hz
Temperature(operating/storage) -20~50°C / -40~60°C
Humidity(operating/storage) 10%~90%RH / 10%~85%RH
MTBF ≥1000hrs
Life Span ≥100000hrs
Pixel Failure <0.0003

Products After-sale Service
1. Three-years warranty for the entire system, except human factors and force majeure Guarantee.
2. One of the year the quality, maintenance of life, and to ensure the maintenance time in the contract.
3. The warranty period: solving problems for users through telephone, fax or email. Update the software for free.
4. As to product quality problems caused by the design, manufacturing, technology installation, equipment, replacement and maintenance are free. System damage caused by force majeure (flood, fire, earthquake, war, and so on) as well as users) artificial disturbance (construction, cleaning) should be coordinated by the two parties to résoudre.Entretien
5. Life long for the system: after the warranty, we charge only the cost of equipment.

80*80 Pixels P8 Led Screen Stage Backdrop , High Definition Led Display Ultra Slim80*80 Pixels P8 Led Screen Stage Backdrop , High Definition Led Display Ultra Slim
