Full Colour DIP346 Billboard LED Display P31.25mm Long Life Span 1024 Pixel / M²
Full Colour DIP346 Billboard LED Display P31.25mm Long Life Span 1024 Pixel / M²
Full Colour DIP346 Billboard LED Display P31.25mm Long Life Span 1024 Pixel / M²
Full Colour DIP346 Billboard LED Display P31.25mm Long Life Span 1024 Pixel / M²
Specifications
Brand Name :
BAKOVISION
Model Number :
ODC-31.25
Certification :
CE/LCC/RoHS
Place of Origin :
CHINA
MOQ :
1 square meter
Price :
$399~999
Payment Terms :
L/C, T/T, ,Visa,e-checking,Visa, Western Union
Supply Ability :
6500㎡/Month
Delivery Time :
20-25days
Packaging Details :
Wooden Case or Flight Case
Pixel Pitch :
31.25mm
Pixel Density :
1024pixel/m²
LED Type :
DIP346
Cabinet Dimension :
1000*250mm /1500*250mm
Brightness :
>6500nits
Cabinet Material :
aluminum
Ingress Protection(front/rear) :
IP65/IP54
Data Refresh Rate :
>1500Hz
Description

P31.25mm DIP Billboard LED Display, Long Life Span Digital Full Colour LED Board

BakoVision LED Video wall for outdoor applications is a module based LED wall solution.

The technology used in BakoVision outdoor LED displays is DIP. As this is a module based solution,

it can be molded into any shape or size.

Due to DIP technology that is used the outdoor video walls are sturdy, durable & very bright. Unlike other LED video walls, BakoVision outdoor LED displays are viewable in direct sunlight. The picture quality is not compromised in our solution, hence the display is crystal clear despite it’s a day time or night time.

We strive to create products which are environmentally balanced, BakoVision outdoor LED video walls are low power consumption.

Our outdoor LED displays are compatible with various input formats, such as DVD players, cable TV, internet & intranet etc.

These are highly customized LED walls, every LED video is customized in regards to pixel pitches, resolution, sizes, shapes etc.Our LED video walls enjoys long life, they are weatherproof units & can tolerate dust, humidity or rain.

Full Colour DIP346 Billboard LED Display P31.25mm Long Life Span 1024 Pixel / M²

Full Colour DIP346 Billboard LED Display P31.25mm Long Life Span 1024 Pixel / M²

Full Colour DIP346 Billboard LED Display P31.25mm Long Life Span 1024 Pixel / M²

Model ODC-31.25
Pixel Pitch 31.25mm
Pixel Density 1024 px/m2
LED Type DIP346
LED Configuration 1R1G1B
Cabinet Dimension

1000*250mm/1500*250mm
Cabinet Resolution 32*8px/48*8px
Cabinet Weight 3.5kg/5kg
Cabinet Material aluminum
Ingress Protection(front/rear) IP65/IP54
Brightness >6500nits
Viewing Angle(H/V) 110°/70°
Driving Method Static driving
Frame Refresh ≥ 60Hz
Data Refresh Rate >1500Hz
Gray Scale 16bit
Power Consumption(avg.) 250w/m2
Input Voltage

AC110/220±10%,

50~60Hz
Temperature(operating/storage)

-20~50°C /-40~60°C
Humidity(operating/storage) 10%~90%RH / 10%~85%RH
MTBF ≥1000hrs
Life Span ≥100000hrs
Pixel Failure <0.0003
