High Brightness Billboard Led Display For Outdoor Ads With 1024*768 Aluminum Cabinet
High Brightness Billboard Led Display For Outdoor Ads With 1024*768 Aluminum Cabinet
High Brightness Billboard Led Display For Outdoor Ads With 1024*768 Aluminum Cabinet
High Brightness Billboard Led Display For Outdoor Ads With 1024*768 Aluminum Cabinet
High Brightness Billboard Led Display For Outdoor Ads With 1024*768 Aluminum Cabinet
High Brightness Billboard Led Display For Outdoor Ads With 1024*768 Aluminum Cabinet
Specifications
Brand Name :
bakovision
Model Number :
P2.6/P3.2/P5.33/P6.4/P8/P12.8/P16
Certification :
CE, Rohs, ETL, FCC
Place of Origin :
China
MOQ :
1pcs
Payment Terms :
Western Union, L/C, T/T, D/P
Supply Ability :
1000pcs 20-25 days
Delivery Time :
20-25days
Packaging Details :
wooden box or flight case
Pitch :
P2.6/P3.2/P5.33/P6.4/P8/P12.8/P16
maitenance service :
front access
Cabinet material :
Aluminum die-casting
Module size :
512*256mm
Cabinet size :
1024*768mm
Driver IC :
MBI5124
Leds :
SMD2727
Price :
$399~999
Description

High Brightness Billboard Led Display for Outdoor Ads, Aluminum Cabinet Size of 1024*768

Description:

1. Module and cabinet achieving front&rear maintenance;

2. IP65 super waterproof;

3. Fast and easy dismounting,saving much time and cost;

4. Screen body front maintenance,reducing installing structure material,thinner body,saving installation cost;

5. Fast lock and single cable design for rear cabinet,30s only for dismounting a module;

6. Using integrated design,combine the cables and control system,make the back cabinet more

tidy and artistic;

7.Waterproof ring and removable patent design ensures the high waterproof grade and easy

maintenance;

8. Easy operation on screen body,module,control box and cables,convenience for transportation

Features:

1. Pitch of 2.6mm, 3.2mm, 5.33mm, 6.4mm, 8mm, 10.66mm, 12.8mm, 16mm are available, what’s more they share the same aluminum die-casting cabinet;

2. Solid but light: due to aluminum die-casting design, it’s only 35kg/sqm, while normal iron cabinet is 55kg/sqm, so it save more labor and cost;

3. Excellent heat dissipation, due to aluminum module frame design;

4. Dynamic seamless pictures always avialble;

It’s can be used for rental business and sport events;

Specification

Pixel pitch 12.8 mm
Pixel density(dots/m2) 6103
LED encapsulation SMD 2727
Cabinet weight (Kg) 27.7
Module size(mm) 512*256
Cabinet size(mm) 1024*768
Brightness (cd/㎡) ≥5500
View angle 160°(horz.)/ 140° (vert.)
Refresh rate ≥1920 Hz
Grey scale 14~16 bit
Operating Temperature(℃) -20~50
Protection grade IP65/IP54
Service Front/Rear

High Brightness Billboard Led Display For Outdoor Ads With 1024*768 Aluminum CabinetHigh Brightness Billboard Led Display For Outdoor Ads With 1024*768 Aluminum Cabinet
