Specifications
Brand Name :
BAKOVISION
Model Number :
BG-3.9-7.8
Certification :
CE RoHS EMC UL
Place of Origin :
China
MOQ :
1 square meter
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
8000 square meter per month
Delivery Time :
20-25 work days
Packaging Details :
Flight Case
Unit Weight :
10kg
Transparency :
68%
Viewing Angle(H/V) :
140°/140°
Application :
Storage-40~60°C, Working-20~50°C
Protection Level :
IP30
Power Consumption(AVG.) :
180w/m²
Max Brightness :
>6500nits
Driving Method :
1/6 scan
Description

Indoor fixed LED Display Magic window Transparent Glass Screen P3.9-7.8 RGB HD Energy Saving High Brightness​

Transparent LED Display Description:

  1. SMD 3-in-1 LED guarantees widely viewing angle and great color uniformity.
  2. High definition brings excellent performance.
  3. Specially designed aluminum cabinet insures convenient installation.
  4. Professional lock design makes seamless connection available.
  5. You could enjoy HD video performance due to its high refresh rate .
  6. Using at indoor locations with short and middle viewing distance.

Our avantages:

  1. The unit price depends on the quantity, we can offer you at a competitive price.
  2. Your inquiry related to our products or prices will be replied in 24hours.
  3. Well-trained and experienced staffs to answer all your enquiry regarding products.
  4. Distributorship are offered for your unique design and some our current models.
  5. Protection of your sales area, ideas of design and all your private information.

How to maintain led screen?

In usually every year to maintain led screen one time,clear the led mask,checking the cables connection,if any led screen modules fail,you can replace it with our spare modules.

Technical Specification

Model BG P3.9-7.8
Pixel Pitch(H/V) 3.9-7.8mm
Unit Size 1000mmx500mm
LED Type SMD1921
Pixel / Unit 128*16
Unit Weight 14kg/sqm
Transparency 68%
Viewing Angle(H/V) 140° / 140°
Application Storage-40~60°C, Working-20~50°C
Protection Level IP30
Power Consumption(AVG.) 180w/m2
Frame Refresh ≥ 60Hz
Data Refresh Rate >1500Hz
Processing 16bit
Max Brightness >6500nits
Driving Method 1/6 scan
Power Supply AC110/240V, 50~60Hz
MTBF ≥1000 Hours
Life Span ≥100000 Hours
Pixel Failure <0.0003

1/6 Scan Indoor Fixed LED Display Magic Window Transparent Glass Led Screen

1/6 Scan Indoor Fixed LED Display Magic Window Transparent Glass Led Screen

Shenzhen BAKO VISION Technology Co., Ltd, started in Shenzhen in 2005,a world class manufacturer of

technologically advanced LED displays,it is fully capable to provide the tailor work of OEM, ODM, creative LED models beside of standard LED screens.

BAKO VISION product lines have include I/O rantal,I/O fixed, UHD fine pitch, transparent screen,advertising poster,foldable screen… meanwhile, based on our experienced R&D team,and comprehensive management , we are always open and been proficient in breaking new model and tooling for customized solutions as well as creative products.

FAQ

Q1:How to choose a proper led screen for your need?


A:You just need to think of 3 simple questions when you choose a led screen by yourself.
1.Will you use it indoor or outdoor?
2.Is it for rental use(need to be moved from one place to another place very often) or for fixed installation(to be installed in one place forever)?
3.what is the appoximate size of the led screen you would like to purchase?

Q2:Which pixel pitch should i choose?


A:There are many different pixel pitch from 1.667--20,25,30mm, there is a roughly principle-usually small pixel(1.667mm-10mm) used for indoor led screen, bigger pixel (10mm-30mm) used for outdoor led screen(for example high way huge advertisement).


Q3:Which control system should i choose?


A:There is both synchronous and asynchronous control system for led screen on the market,for big size led screen(usually more than 20sqm) need to use synchronous control system,below 20sqm it's up to you to use syn or asyn.But asyn control system's refresh rate is much lower than sync control system and for asyn control system, you can choose to use wifi,3G,4G etc wireless control.
