Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Specifications
Brand Name :
VIKSTARS
Model Number :
VS-SSL-L
Certification :
CE, CB, ROHS, AS Required
Place of Origin :
Guangdong, China
MOQ :
20pcs
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
16000pcs per Month
Delivery Time :
15-25 days
Packaging Details :
ITEM: VS-SSL-L30 Lamp size: 550*255*90 mm, Solar panel size: 530*350*17mm, Ctn size: 610*155*435mm 1pc/ctn
Lamp Power :
300W 500W 600W 1000W 1600W
Install Ways :
pole install, wall install, hug hoop install
Waterproof :
IP66 Waterproof
Application :
Street,main Road, Pathway,walkway,yard,park,landscape,square
Install Height :
5-10m
Description

Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street

​PARAMETERs​
.
LAMP NAME
L Series - Solar Street Lights
MODEL NO.
VS-SSL-L03
VS-SSL-L05
VS-SSL-L06
VS-SSL-L10
VS-SSL-L16
POWER
300W Project Solution
500W Project Solution
600W Project Solution
1000W Top-level Solution
1600W Top-level Solution
BATTERY
3.2V 24AH Lithium
3.2V 36AH Lithium
3.2V 60AH Lithium
3.2V 100AH Lithium
12.8V 60AH Lithium
SOLAR PANEL
Mono 5V 30W
Mono 5V 50W
Mono 5V 60W
Mono 6V 100W
Mono 18V 120W
LUMEN
1760lm
2880lm
3840lm
5400lm
10800lm
LED QTY
SMD5054*80PCS, 4-chip 1530
Brightlux SMD5050*80pcs, 4-chip 1734
BEAM ANGLE
120°
CCT
Cold White
CHARGE TIME
4-6 hours
LAST TIME
16-18 hours / 3-5 Rainy days
INSTALL HEIGHT
4-5m
4-6m
5-7m
6-8m
8-10m
LIGHT AREA
100㎡
200㎡
300㎡
400㎡
800㎡
WORK MODE
Intelligent Light control + Time Control + Remote Control

INSTALL WAY
Pole / Wall / Hug Hoop Installation
(accessories not include hoop, need buy additionally)
WATERPROOF
IP66
MATERIAL
High Quality Aluminum Heat Sink + PC lens / Sand Grey
LAMP SIZE
550*255*90mm (same size for all series)
PANEL SIZE
530*350*17mm
670*445*25mm
670*535*25mm
670*915*30mm
670*1020*30mm
PACKING
Integrated Packing (Export Neutral Carton / VIKSTARS Brand / Customizing Packing)
Customized According to Projects
WARRANTY
2 Years warranty
SOLUTIONs
REAL PHOTOs​
INSTALLATIONs
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Project Solution--battery built-in
300w/500w/600w

Top-level Solution--external battery box
1000w/1600w

3 Installations of Project Solution
Top-level solution installation according to project

Wall Install

Pole Install

Hug Hoop Install
​ SIZEs​
Manually Measured, Tolerances Is Possible
same size for all watts 300w: 500mm length
500w: 600mm length
 300w: total length 970mm
500w: total length 1070mm

project solution 300w project solution 500w project solution 600w

top-level solution 1000w solar panel
top-level solution 1600w solar panel

ACCESSORIEs

​ PACKING​

Solution
 Power Carton Size pc/ctn
N.W.
 Specification
Project Solution
300W
610*155*435mm
 1pc/ctn 5.00kg
Battery built-in the lamp body, integrated packing
500W 720*155*495mm 1pc/ctn 6.50kg
600W
/
/
/
Battery built-in the lamp body, But because of the bigger size solar panel, need customize packing
Top-level Solution
1000W
/
 / /
Outter battery box, larger size solar panel, need customize packing according to the project
1600W / /
/

300W/500W - Integrated Packing
600W with larger size solar panel, need to customize packing

300W/500W Project Solution Carton
600W with larger size solar panel, need to customzie packing
INTELLI LIGHT CONTROL
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
DETAILs
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
PROJECTs Live Photos
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
ORIGIN FACTORY
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
Hottest Sales Solar LED Street Lights 300W 500W 1600W For Project Village Industrial Park Main Street
