10° Narrow Viewing Angle LED Lens with 93% Efficiency and PMMA Material for COB Light Sources
10° Narrow Viewing Angle LED Lens with 93% Efficiency and PMMA Material for COB Light Sources
Specifications
Brand Name :
Wisertop
Model Number :
WT-40@20-10COBL6-Y1
Certification :
Rohs
Place of Origin :
China
MOQ :
1pc
Price :
Shenzhen Wisertop Technology Co.,Ltd
Supply Ability :
100,000 day
Delivery Time :
1-2 weeks
Packaging Details :
Master carton
Material :
PMMA
Lens type :
TIR Lens
Efficiency :
93%
Certificates :
Rohs
Working temperature :
-40°C~+70°C
Light source :
Brand COB leds as Cree Osram Lumileds Bridgelux...
Description
10 Degree LED Lens PMMA LED Spotlight Lens Match Lumileds COB
Product Overview

Narrow viewing angle 10° lens made from PMMA material for spotlight applications, compatible with Lumileds COB. Diameter: 40mm.

Applications
  • Spot light
  • Down light
  • Tracking light
  • Recessed lamp
  • Ceiling light
Lens Material & Features

Lens material: PMMA (all available)

  • High K value
  • Accurate viewing angle - illuminated object is clear and recognizable
  • High light transmittance
  • Maintains high color resistance
  • Main light halo fades naturally
  • Low glare and good shape light area
Compatible COB Light Sources

Cree, Lumileds, Bridgelux, Citizen, and more.

Specifications
Part no Light-emitting surface FWHM Size (mm) Typ.eff Material
WT-40@20-10COBL6-Y1 ¢6mm COB 10° φ39.8×20 93% PMMA
WT-40@20-15COBL6-Y1 ¢6mm COB 15° - 93% PMMA
10° Narrow Viewing Angle LED Lens with 93% Efficiency and PMMA Material for COB Light Sources 10° Narrow Viewing Angle LED Lens with 93% Efficiency and PMMA Material for COB Light Sources
Frequently Asked Questions
1) Can I have a sample order?
Yes, we welcome sample orders to test and check quality. Mixed samples are acceptable.
2) When can I get the quotation?
We usually provide an offer within 12 hours after receiving your inquiry. For urgent requests, please call or email us.
3) What is the lead time?
Samples require about 3-5 days for preparation. Mass production typically takes 1-2 weeks.
4) What are your main products?
Our main products are indoor lenses.
