FCC 6500K 25W 300lm 500mm Length Edge Light Bar
FCC 6500K 25W 300lm 500mm Length Edge Light Bar
FCC 6500K 25W 300lm 500mm Length Edge Light Bar
FCC 6500K 25W 300lm 500mm Length Edge Light Bar
FCC 6500K 25W 300lm 500mm Length Edge Light Bar
FCC 6500K 25W 300lm 500mm Length Edge Light Bar
Specifications
Brand Name :
Phenson
Model Number :
PS-C403
Certification :
CE,ROHS FCC
Place of Origin :
Shenzhen,China
MOQ :
100pcs
Payment Terms :
Western Union, T/T
Delivery Time :
7~10 days
Beam angle :
15x45°
Part No :
PS-C403
Working voltage :
DC24V
LED source :
CSP1818
Power /piece :
15W/20W/25W
lm/Heart :
300lm
Length :
300/400/500mm
LED Qty :
6pcs/8pcs/10pcs
IP grade :
IP65
Produce name :
LED edge light bar
PCB material :
Aluminium
Description

LED Edge Light Bar High Power Constant Current Side Light Strip 300lm 6500K

Product features ,
1. DC24V low voltage input, safe and reliable, wide range of
application.
2. High power constant current drive to ensure LED brightness
consistency and lamp box uniformity.
3. Using Taiwan new century CSP1818 high power LED, good heat
dissipation, large current, high reliability.
4. Adopt 2.0mm thick and high thermal conductivity aluminum
substrate to dissipate heat and improve the service life of products.
5. With an optical lens of 15X45°, the light scatters from both
directions, ensuring the uniformity of the light source, no macula,
and the irradiation distance up to 3m.
6.Fixed with hard anti-rust screw, never drop when using,
environmental protection and maintenance-free.
7. 6063 aviation aluminum profile heat dissipation, silicone
waterproof, effectively solve the problem of waterproof heat
dissipation.

Part No. CCT Working voltage LED source W/pcs Lm/Heart Length(mm) LED Qty
PS-C403-6D 6500K DC24V CSP1818 15 300 300 6pcs
PS-C403-8D 6500K DC24V CSP1818 20 300 400 8pcs
PS-C403-10D 6500K DC24V CSP1818 25 300 500 10pcs

FCC 6500K 25W 300lm 500mm Length Edge Light Bar

FCC 6500K 25W 300lm 500mm Length Edge Light Bar

FCC 6500K 25W 300lm 500mm Length Edge Light Bar

FCC 6500K 25W 300lm 500mm Length Edge Light Bar

FCC 6500K 25W 300lm 500mm Length Edge Light Bar

FCC 6500K 25W 300lm 500mm Length Edge Light Bar

FCC 6500K 25W 300lm 500mm Length Edge Light Bar
