Specifications
Brand Name :
PHENSON
Model Number :
0911 / 0310 / 0278
Certification :
CE ROHS
Place of Origin :
CHINA
MOQ :
1PCS
Price :
negotaible
Payment Terms :
T/T
Supply Ability :
10000pcs/month
Packaging Details :
1pcs per carton
Color Temperature(CCT) :
3000-6000K
CRI (Ra>) :
80
Charging Time :
6-8 hours
Input Voltage(V) :
5V-18V
Lifespan (hours) :
50000
Warranty :
3 Years
Description

Outdoor Waterproof All In One LED Solar Street Light Aluminum 200w 300w 400w

Feature :

Product name : All in one solar street light

Place of Origin: Guangdong, China

Brand Name: PHENSON

Model Number: 0911 / 0310 / 0278

Application: Highway, Garden, Courtyard, Road, Outdoor, etc.,

Color Temperature(CCT): 3000-6000K

IP Rating: IP65

Beam Angle(°): 120

CRI (Ra>): 80

Input Voltage(V): 5V-18V

Lamp Luminous Efficiency(lm/w): 160

Lamp Luminous Flux(lm): 25600-57600lm

Warranty(Year): 3-Year

Working Temperature(℃): -20 - 60

Color Rendering Index(Ra): 80

Certification: RoHS, ce

Power Supply: Solar

Light Source: LED

Support Dimmer: Yes

Lighting solutions service: Lighting and circuitry design, auto CAD layout, Agi32 layout, Project Installation

Lifespan (hours): 50000

Working Time (hours): 50000

Type: Outdoor All In One Solar Led Street Light

Power: 50w 100w 150w 200w 250w 300w 400w

Solar Panel: Polycrystalline

Battery Type: LiFePO4

Charging Time: 6-8 hours

Discharging Time: 30-36 hours

Material: Aluminum

Warranty: 3 Years

LED Light Source: SMD

Product Parameter :

Brand Name
ALLTOP
Item No.
0911A50-01
0911B100-01
0911C150-01
Power
50W
100W
150W
Lamp Size(mm)
532*343*150mm
642*343*150mm
1004*343*150mm
Solar Panel
18V 36W, Mono-Crystalline
18V 45W, Mono-Crystalline
18V 65W, Mono-Crystalline
Battery type
LiFePO4 12.8V 18AH
LiFePO4 12.8V 30AH
LiFePO4 12.8V 42AH
Item No.
0911D200-01
0911E250-01
0911F300-01
Power
200W
250W
300W
Lamp Size(mm)
1192*343*150mm
1472*343*150mm
1783*384*150mm
Solar Panel
18V 88W, Mono-Crystalline
18V 100W, Mono-Crystalline
16.5V 130W, Mono-Crystalline
Battery type
LiFePO4 12.8V 54AH
LiFePO4 12.8V 60AH
LiFePO4 12.8V 72AH
Material
Aluminum Alloy
Charging time
6-8 hours
Discharging time
30-36 Hours
Application
Lights for street,highway,garden,square or any other outdoor place
Warranty
3 Years
Brand Name
Phenson
Item No.
0278
0310
Power
200w
300w
400w
200w
300w
LED Lamp
5050LED84PCS 6000K
5050LED126PCS 6000K
5050LED168PCS 6000K
5050LED168PCS
3000K-6000K
5050LED252PCS 3000K-6000K
Solar Panel
18V88W, Mono-Crystalline
18V100W,
Mono-Crystalline
16.5V130W, Mono-Crystalline
16.5V180W,
Mono-Crystalline
8V200W,
Mono-Crystalline
Product Size
1207*358*303
1487*358*303
1800*400*303
1550*534*174
1767*534*174
Install Height
5-7m
6-8m
7-9m
8-10m
8-10m
Material
Aluminum
Charging Time
6-8 Hours
Discharging Time
30-36 Hours
Warranty
3 Years
Application

Highway,Garden,Paking Lot, Park,Road, Square, etc.

Outdoor Waterproof All In One LED Solar Street Light Aluminum 200w 300w 400w

Outdoor Waterproof All In One LED Solar Street Light Aluminum 200w 300w 400wOutdoor Waterproof All In One LED Solar Street Light Aluminum 200w 300w 400wOutdoor Waterproof All In One LED Solar Street Light Aluminum 200w 300w 400wOutdoor Waterproof All In One LED Solar Street Light Aluminum 200w 300w 400wOutdoor Waterproof All In One LED Solar Street Light Aluminum 200w 300w 400wOutdoor Waterproof All In One LED Solar Street Light Aluminum 200w 300w 400w

Production workshop

Outdoor Waterproof All In One LED Solar Street Light Aluminum 200w 300w 400wOutdoor Waterproof All In One LED Solar Street Light Aluminum 200w 300w 400w

Product Features:

1.“All in One solar steer light ” could not work without sunshine, please select the suitable model according to the local sunshine radiation and the annual total radiation. We suggest use the both AC and DC charging model in those places where lack of sunshine or have long-time rainy days.

2.“All in One solar street light” adopts the long life Lithium battery for storing energy, charging temperature at day time is between: 0℃~+60℃, when temperature goes lower than 0℃, the control system will stop automatically to protect the battery, and it will revive to charge the battery while temperature goes higher than 0℃. Discharging temperature at night is between: -20℃~+60℃, any ambient beyond will take damage to the battery. So please check these factors while selecting the street light.

3.Battery of the “All in One solar street light” can be stored for 6 months long after fully charged.Therefore please examine and charge it periodically after long time transportation or storage to prevent damaging.

4.When install the lights in Northern Hemisphere, please adjust the solar panel to the South as much as possible to collect maximum sunshine radiation, while install them in Southern Hemisphere, By the same token, keep solar panel to north. At the same time please keep it away form any shadow of houses, trees etc.

5.Keep clear of the surface of the All in One solar street light with normal detergent to get maximum power generation, clear the dust or tree leaves or any grease.

6.All in One solar street light have got the standard of IP65. The vents on the surface is designed for radiating. The materials are made of aluminum alloy which can survive in the environment of seaside and desert.
