Aluminium Treliça Bolt Spigot Truss System For Display Event
Aluminium Treliça Bolt Spigot Truss System For Display Event
Aluminium Treliça Bolt Spigot Truss System For Display Event
Aluminium Treliça Bolt Spigot Truss System For Display Event
Aluminium Treliça Bolt Spigot Truss System For Display Event
Aluminium Treliça Bolt Spigot Truss System For Display Event
Aluminium Treliça Bolt Spigot Truss System For Display Event
Aluminium Treliça Bolt Spigot Truss System For Display Event
Specifications
Brand Name :
LEDIKA
Model Number :
TRB/TRS
Certification :
TUV
Place of Origin :
Guangzhou,China
MOQ :
10pcs
Price :
USD100-300/M
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
50,000M/ month
Delivery Time :
15-20 working days
Packaging Details :
Carton with film / Flight case / Wooden box
Model :
Aluminum Truss
Connection :
Bolt / Spigot
Shape :
Triangle
Series :
Light series
Feature :
Lightness,Stabilization
Packing :
With Carton + Film
Color :
Silver, Red, Blue or as customized
Description

Aluminium Treliça Bolt Spigot Truss System For Display Event


Product Description


Aluminum Truss uses international standard 6082 material, with the advantages of beautiful appearance,small volume, easy to set up and transport, itself also has the advantages of excellent compressive and anticorrosive performance; the truss average loading can meet many kinds of performances, business conferences audio equipment requirements. Other irregular shapes can be customized according to the customers' requirements.


Product's Material

  • Material : 6082 Aluminum
  • Color : Silver, Black, Red, Green or Customized
  • Standard: TUV , ISO9001
  • Truss Shape: Customised

Specification

Item NO.

 TRB400 TRB300 TRB387 TRB287
Truss Shape Triangle Triangle Triangle Triangle
Size of Truss 400x400mm 300x300mm 387x387mm 287x287mm
Length 0.5M-3M 0.5M-3M 0.5M-3M 0.5M-3M
Main Tube Diameter Ø 50mm , Thickness 3mm Diameter Ø 50mm , Thickness 3mm Diameter Ø 50mm , Thickness 3mm Diameter Ø 50mm , Thickness 3mm
Vice Tube 50x25mm Strenghten quadrate 50x25mm Strenghten quadrate / /
Standpipe Diameter Ø 30mm , Thickness 2mm Diameter Ø 30mm , Thickness 2mm Ø 50mm Spigot Ø50mm Spigot
Brace Tube Diameter Ø 30mm , Thickness 2mm Diameter Ø 30mm , Thickness 2mm Diameter Ø 30mm , Thickness 2mm Diameter Ø 20mm , Thickness 2mm
Max Span 12M 12M 12M 12M
Max Loading 510-950kg 250-780kg 450-770kg 220-680kg


View

Aluminium Treliça Bolt Spigot Truss System For Display Event

Aluminium Treliça Bolt Spigot Truss System For Display Event

Aluminium Treliça Bolt Spigot Truss System For Display Event


Aluminium Treliça Bolt Spigot Truss System For Display Event


Applications:
Concert, Outdoor and indoor performance and shows, Exhibitions,etc



Type of Trading

Payment Terms T/T, L/C, Western Union
Payment 50% TT in davance, the balance should be against before shipment
Delivery 15-20 working days after receive your deposit




FAQ

1. Q: Are you a dealer?
A: No. We have our own factory that covers an area of 3,000 square meters.
2. Q: Can you make customized products?
A: Absolutely. You just need to send us your requirement about the item or design.
3. Q: What does your factory do regarding quality control?
A: Quality is our priority, we pay great attention to the quality from the beginning to the end.
And we never sell low quality products for lower price.
