P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm
P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm
P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm
P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm
P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm
P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm
P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm
P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm
Specifications
Brand Name :
VW
Model Number :
P6.67
Certification :
CE, ROHS, EMC
Place of Origin :
CN
MOQ :
Negotiate
Price :
Negotiate
Payment Terms :
T/T, L/C
Supply Ability :
2000sqm/month
Delivery Time :
15 work days
Packaging Details :
Plywood case
Product Name :
P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm
LED Type :
SMD3535
Cabinet Dimension :
960x960mm
Chip Color :
RGB full color
Pixel Density :
28224 dots/sqm
Maintenance :
Rear service
Cabinet Weight :
38 kg
Application :
outdoor wall mounting advertising video wall
Module Connection :
Locks
Brightness :
5500 nits
Description

P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm

Product Description:

Fixed led display screen refers to the led display screen installed in a fixed position. It can be separated into indoor and outdoor installation depending on the conditions. With powerful features including light weight, dust prevention, waterproofness, high temperature resistance, flame retardancy, automatic power on/off and brightness control. Visual World offers the most stable and long service life outdoor fixed installation led displays.

Features:

  • Waterproof:Durable, waterproof, fast heat dissipation aluminum cabinet with ip65 protection level for outdoor using.
  • Front service:The cabinet and module have compatible front locks design which allows technicians to do front maintenance effortless.
  • High brightness:Customized module pcb and designated power supply make it up to 6000nits brightness.
  • Wide viewing angles:Wide viewing angles horizontal 140°, vertical 140° allows audience to watch the screen clearly from distances.
  • Quick installation:Simple internal cables connection and positioning pins, quick and easy installation.

Technical Parameters:

Product Model: P5 P5 P5.926 P6 P6.67 P8 P8
Pixel Pitch: 5mm 5mm 5.926mm 6mm 6.67mm 8mm 8mm
LED Type: SMD1921 SMD1921 SMD2727 SMD2727 SMD3535 SMD3535 SMD3535
Cabinet Dimension: 960x960mm 960x960mm 960x960mm 960x960mm 960x960mm 960x960mm 960x960mm
Module Size: 160×160mm 320×160mm 320×160mm 192×192mm 320×160mm 256×128mm 320×160mm
Maintenance Rear service Rear service Rear service Rear service Rear service Rear service Rear service
Cabinet Weight: 38 kg 38 kg 38 kg 38 kg 38 kg 38 kg 38 kg
Cabinet Material: Steel Steel Steel Steel Steel Steel Steel
Driving Type: 1/8 1/8 1/7 1/8 1/6 1/4 1/5
Brightness: 5200 nits 5200 nits 5800 nits 5000 nits 5500 nits 5500 nits 5800 nits
Max/Avg Power: 800/280 W/m2 800/280 W/m2 800/280 W/m2 800/280 W/m2 800/280 W/m2 800/280 W/m2 800/280 W/m2
Environment: Outdoor Outdoor Outdoor Outdoor Outdoor Outdoor Outdoor
IP Rating: IP65 IP65 IP65 IP65 IP65 IP65 IP65
Refresh Rate: >1920 Hz >1920 Hz >1920 Hz >1920 Hz >1920 Hz >1920 Hz >1920 Hz
Installation Type:

Mounting

/Hanging

Mounting

/Hanging

Mounting

/Hanging

Mounting

/Hanging

Mounting

/Hanging

Mounting

/Hanging

Mounting

/Hanging
Gray Scale: 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit 14 bit
Viewing Angle: H:140°；V:120° H:140°；V:120° H:140°；V:120° H:140°；V:120° H:140°；V:120° H:140°；V:120° H:140°；V:120°
Operational Temp: Outdoor Outdoor Outdoor Outdoor Outdoor Outdoor Outdoor
Operational Humidity: 10%~90% RH 10%~90% RH 10%~90% RH 10%~90% RH 10%~90% RH 10%~90% RH 10%~90% RH

Application:

  • Outdoor creative modeling
  • Building entrance
  • Park entrance
  • Swimming pool
  • Advertising billboard
  • Playing field
  • Outdoor activity area
  • Roadside poster
  • Building exterior wall

P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm

P6.67 Outdoor Fixed LED Video Wall Screen Rear Service 5500nits 960x960mm

FAQ

Q1: The model of LED display screens is generally represented by "P", such as P2, P3, P4... P8, P10. What does this mean?

A1: P3 P4..... P8, P10 indicates that the pixel pitch is 3mm, 4mm... 10mm, which determines the resolution of the display. The smaller the pixel pitch, the higher the resolution of the LED display.

Q2: What pixel pitch should I choose on my display?

A2: It mainly depends on the viewing distance, the size of the display, the desired effect and the customer's budget.

Q3: What information do I have to give you to order a monitor?

A3: You should provide the width/height of the monitor, main use, viewing distance, on-site photos and other special requirements before I can provide you with a detailed quotation list

Q4: How about delivery time?

A4: We will ship as soon as possible, but depending on the distance and some other necessary processes, it usually takes 2-3 weeks to receive the goods.

Q5: What if I don't know how to maintain the screen?

A5: When you place your order, we will provide you with the operating manual and software, and we can help you remotely adjust the software through the team.
