Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition
Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition
Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition
Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition
Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition
Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition
Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition
Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition
Specifications
Brand Name :
VW
Model Number :
P5.2-10.4
Certification :
CE, ROHS
Place of Origin :
CN
MOQ :
Negotiate
Price :
Negotiate
Payment Terms :
T/T
Supply Ability :
2200 sqm/month
Delivery Time :
10 work days
Packaging Details :
Plywood box
Product Name :
Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition
LED Type :
SMD1921
Operating Temperature :
-20℃~+50℃
Lifespan :
100,000 Hours
Module Size :
500x125 MM
Viewing Angle :
H:140°；V:140°
Gray Scale :
14bit
Pixel Pitch :
5.2-10.4mm
Description

Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition


Product Description:

Transparent LED screens provide an effective and compelling alternative to large format LED screens. The images on the screen are created by programming the LED to work together. By displaying the relevant pixel colors on the mapped LED, the lights are brought together to create the image. When integrated into a glass curtain wall, this effect is particularly powerful, allowing designers to provide screen solutions for retail buildings, with a focus on glass buildings without affecting the overall design.


Features:

  • High contrast and brightness:Extra flexibility, weighs under 8.5 Kg/m2 and thinner than 25mm. Very convenient to use and move, saving a lot of transportation and assembling costs
  • Stability long life time:Low power comsumption and energy saving, Low consumption of electricity to increase the lifetime of LED
  • High Transparency and High Brightness:20-80% transparency rate, see through, suitable for glass wall mounting；>6500 nits brightness, for all outdoor environment


Technical Parameters:

Technical Parameters Transparent LED Display
Pixel Pitch:
5.2-10.4 mm
LED Type: SMD1921
Cabinet Dimension: 1000×500mm
Module Size: 500x125 mm
Cabinet Weight: 15 kg
Cabinet Material: Aluminum
Driving Type: 1/6
Brightness: 5000 nits
Max/Avg Power: 800/280 W/m2
Maintenance: Front service
IP Rating: IP65
Refresh Rate: >1920 Hz
Transparent Rate: 60%
Gray Scale: 14 bit
Viewing Angle: H:140°；V:140°
Operational Temp: -20℃~+50℃
Operational Humidity: 10%~90% RH


Applications:

Widely used for shopping malls, entertainment venues, building construction, government agencies, trade fair, fair, aiming at the exhibition, press conference, airports, hotels, internal, station waiting area, indoor stadium, and a variety of public facilities and etc.

Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition

Outdoor P5.2-10.4 High Transparency LED Display 15kg 5000 nits For Exhibition


FAQ:

Q1: LED display models are generally expressed in PX, such as P2 P3 P4.....P8, P10, what does this mean?

A1: P3 P4.....P8,P10 means that the pixel pitch is 3mm 4mm....10mm, which determines resolution of a display. Pixel pitch is smaller, led display resolution is higher.


Q2: What pixel pitch should I choose on my display?

A2: It is determined mainly by the viewing distance, the size of the display screen, the desired effect and the customer budget.


Q3: To order a display, what kind of information do I have to offer you?

A3: You should provide width/height of the display, the main use, the viewing distance, the scene photos, special requirements, then I can provide you with a detailed list of quotations.


Q4: How to install?

A4: Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram, free remote debugging. We can also send our engineers to the site to guide the installation if needed.


Q5: Can I order a sample?

A5: Yes, We welcome customers to order samples to check our product quality of our products and service.
