50W Special Color Led Cob
50W Special Color Led Cob
50W Special Color Led Cob
50W Special Color Led Cob
50W Special Color Led Cob
50W Special Color Led Cob
50W Special Color Led Cob
50W Special Color Led Cob
50W Special Color Led Cob
50W Special Color Led Cob
50W Special Color Led Cob
50W Special Color Led Cob
Specifications
Brand Name :
XUANCAI
Model Number :
XC-19*19/17
Certification :
CE ROHS
Place of Origin :
China
MOQ :
100
Price :
$1.5- $ 3.9
Payment Terms :
T/T, Western Union, Paypal , Alibaba trade assurance
Supply Ability :
10000M / Month
Delivery Time :
3-5 days
Packaging Details :
Blister box packaging
Product Name :
XC-19*19/17 Meat Light
Watt :
20-50w
Current :
500-1200mA
Voltage :
36-39v
CRI :
70
Chip Brand :
Bridgelux
Certificate :
CE ROHS, LM-80
Color temperature :
2700-10000K
Application :
Meatb/ Bread light
Description

2020 Hot Selling 30W-50W Special Color COB led chip for Bread meat fresh fruits vegetables and Clothing light color

Product Specification

Product Name XC-19*19/17 LED COB Chip
Power 30-50w
Current 750-1200mA
Voltage 36-39v
CRI 90
Color Temperature 2700-6500k

Product Applicantions
Tracking Light, Spot Light, Par Light, Bulb Light, Down Light
Absolute Maximum Ratings
Parameter Symbol Rating
Forward Current IF 1800mA
Reverse Current IR 1mA
Operating Temperature TOPR -30℃ To +75℃
Storage Temperature Tst -30℃ To +75℃
Case Temperature Tc 85℃
Junction Temperature TJ 125℃
Soldering Temperature TSOL 350℃± 10℃ For 5 Seconds
ESD Sensitivity ESD 2000V HBM

Product Characteristics

Product Code

Nominal CCT

 CRI(Ra) Luminous Flux(lm) Efficacy ( lm/W )

Forward

Current

(mA)

Voltage

(V)
Ra R9
Min. Min. Min. Typ. Typ. Min. Typ. Max.
XC1917-M1208-C2790-C31 2700K 90 50 4912 5150 112 1200 36 37 38
Absolute Maximum Ratings
Parameter Symbol Rating
Forward Current IF 1800mA
Reverse Current IR 1mA
Operating Temperature TOPR -30℃ To +75℃
Storage Temperature Tst -30℃ To +75℃
Case Temperature Tc 85℃
Junction Temperature TJ 125℃
Soldering Temperature TSOL 350℃± 10℃ For 5 Seconds
ESD Sensitivity ESD 2000V HBM
Product Dimensions
50W Special Color Led Cob
Company Information
50W Special Color Led Cob
50W Special Color Led Cob

Applications

50W Special Color Led Cob

50W Special Color Led Cob

Trade Show

50W Special Color Led Cob

50W Special Color Led Cob
