ICAO Annex 14 Compliant Heliport Rotating Beacon with UV Protected Polycarbonate and 24 Flashes per Minute
ICAO Annex 14 Compliant Heliport Rotating Beacon with UV Protected Polycarbonate and 24 Flashes per Minute
ICAO Annex 14 Compliant Heliport Rotating Beacon with UV Protected Polycarbonate and 24 Flashes per Minute
ICAO Annex 14 Compliant Heliport Rotating Beacon with UV Protected Polycarbonate and 24 Flashes per Minute
Specifications
Standard :
ICAO Annex 14
Base Material :
Powder-coated stainless steel 304
Body Material :
UV protected Polycarbonate
Name :
Helipad Rotating Beacon
Brand Name :
ANNHUNG
Model Number :
AH-HP-R2
Certification :
ISO, ICAO, CE, ROHS
Place of Origin :
CHINA
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union,
Supply Ability :
200/month
Delivery Time :
15days
Operating Voltage :
120VAC, 220VAC,
Available Colors :
White and Yellow(others are optional)
Flash Characteristics :
24 flashes per minute
Description
ICAO Annex 14 Heliport Rotated Beacon

Helipad Rotating Beacon Airport Beacon 2-color heliport rotated beacon

The heliport beacon shall be located on or adjacent to the heliport preferably at an elevated position and so that it does not dazzle a pilot at short range.

This Rotated beacon is for night operation as identification and location markers for airports.

Compliance
  • FAA L-801A
  • ICAO Annex 14 Volume I 5.3.3
Features
  • 100,000 hour typical lamp life
  • One white color, another yellow color
  • No maintenance
  • All moving parts are permanently lubricated
  • Impedance-protected motor eliminates burnouts
  • 12RPM rotation, 24 flashes/minute
  • Weatherproof stainless steel cabinet, powder-coated international yellow
ICAO Annex 14 Compliant Heliport Rotating Beacon with UV Protected Polycarbonate and 24 Flashes per Minute
Application
  • Helipad/Heliport/Helideck
  • Airport
Specifications
Specification AH-HP-R2 Airport Rotating Beacon
Light Characteristics
Light Source LED
Colors White and Yellow (others are optional)
Flash Characteristics 24 flashes per minute
Light intensity ≥2500cd
Operation Mode Steady burning
LED Life Experience (hours) >100,000
Electrical Characteristics
Operating Voltage 220/240AC
Circuit Protection Integrated
Physical Characteristics
Body Material UV protected Polycarbonate
Base Material Powder-coated stainless steel 304
Mounting 390×70×θ12
Dimension (mm) 566×260×740
Weight (kg) 22
Product Life Expectancy Average 5 years
Environmental Factors
Ambient Temperature (°C) -55℃~+70℃
Humidity 10~90%
Wind Speed 80m/s
Waterproof IP66
Compliance
FAA FAA L-801A
ICAO ICAO Annex 14 Volume I 5.3.3
Options Available

Additional customization options are available upon request.

Download Datasheet: AH-HP-R2 Airport Rotating Beacon.pdf
