Specifications
Brand Name :
Grace Visual
Model Number :
DF Series
Certification :
CCC, CE, ETL, RoHS
Place of Origin :
China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
Negotiation
Delivery Time :
Negotiation
Packaging Details :
Flight case:6 panels into 1 Case, 8 panels into 1 Case
Description

Interactive & Non-Interactive LED Floor Screen DF Series P2.5–P4.8 High Load Capacity 3840Hz High Refresh Rate

High-strength LED floor tiles with pixel pitches from 2.5mm to 4.8mm, offering interactive and non-interactive options for immersive stages and events.

Product Overview:
The DF Series LED floor display offers outstanding durability, seamless visuals, and creative flexibility. Designed for both interactive and non-interactive use, it is perfect for stages, exhibitions, and commercial installations. With pixel pitches from 2.5mm to 4.8mm, and a refresh rate of 3840Hz, the DF Series delivers smooth, high-definition visuals while withstanding heavy loads for safe public use.

Key Features:

·Multiple Pixel Pitches Available: 2.5mm, 2.6mm, 2.97mm, 3.91mm, 4.81mm
·Modular Design: Quick installation and easy maintenance
·Interactive and Non-Interactive Options: Flexible for various events and designs
·High Load Capacity: Specially engineered for safe large-crowd environments
·Seamless Visual Experience: Perfect image consistency without gaps
·Front Maintenance: Easy access for repairs and servicing
·Dustproof and Waterproof: Rugged PC material mask ensures durability
·Energy Saving: Lower power consumption with high performance

Specification


 DF-2.5 DF-2.6 DF-2.9 DF-3.9 DF-4.8
Physical Pitch2.5 2.5mm 2.6mm 2.97mm 3.91mm 4.81mm
Pixel Configuration SMD2121 SMD2121 SMD2121 SMD2121 SMD2121
Module Dimension 250X250mm
Panel Dimension 500X500mm / 500X1000mm
Module Resolution 100X100px 84X56px 72X48px 60X40px

48X32px
Panel Resolution

200X200px

200X400px

192X192px

192X384px

168X168px

168X336px

128X128px

128X256px

104X104px

104X208px
Panel Material Cold steel / Aluminum
Refresh Rate 3840HZ
Viewing Angle(H/V) 160°/140°
Application Indoor
