Specifications
Brand Name :
Singheng
Model Number :
P4
Certification :
CE RoHS UL FCC
Place of Origin :
China (Mainland)
MOQ :
1 square meter
Price :
USD+To be negotiated+square meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000+square meter+per month
Delivery Time :
About 16 days
Packaging Details :
Plywood case
Pixel pitch :
4mm
Pixel Configuration :
1R1G1B
Refresh frequence :
>1920Hz
Life span :
100,000 hours
Module size :
256*128 mm
Module resolution :
64*32 dots
Pixel density :
62500 dots/sqm
Uniformity :
97%
Data transafer method :
RJ45
MTBF :
10,000 hours
Description

Led Panel Full Color P4 Small Led Display Indoor Usage Led Board Price

  • Product Description

1. Video, graphics,other programs and various information can be played in real-time, synchronous and clear information dissemination.

2. The color is realistic and the adaptability is strong.

3. Light weight, single-handed, easy to install.

4. Accurate, shortcut, flexile installation, can be applied to any different installation environment.

5. It adopts synchronous control system processing and can accept various video input signals such as DVI, VGA and HDMI.

6. Ideal for outdoor advertisement media, government& enterprise project culture & tourism, sports, propaganda Image, commercial real estate.

7. We have many models : P4 ,P5, P6, P8, P10 . The definition and prices differ a lot . You can choose based on the installation environment and your budget.

  • FAQ

Q2:What pixel pitch should I choose on my display?
A:Using the PX screen, it is determined mainly by the viewing distance, the size of the screen, the desired effect and the customer budget. It is generally believed that P5 is suitable for watching outside 5 meters. P10 is suitable for watching outside 10 meters. Of course, this data is not very accurate, and the customer can just refer to it. It also depends on the size of the screen, generally it is considered that more than 100 thousand pixels for a full color display then have a standard effect.

Q2:Can I order a sample?
A:Yes.We welcome customers to order sample to check the quality and service.

Q3:How to install?
A:Free of charge to provide detailed steel structure drawings and installation guidance, wiring diagram and free remote debugging .We can also send our engineers to the site to guide the installation.

Q4:How about your quality?
A:The quality of our display is excellent. We use the materials of high quality suppliers, strictly control the production process. and pass the multiple quality inspection to ensure every product is qualified.

Q5:What about the lead time?
A:Orders less than 50 square meters display ,lead time is 16 days.

  • Technical Prameters​ of P4 Small Led Display

Pixel pitch 4mm
Pixel Configuration 1R1G1B
LED component SMD2121 black
Size of module 256mm x 128mm
Resolution of module 64x32
Size of cabinet 1024mm x 1024mm x 110mm
Resolution of cabinet 256x256
Material of Cabinet Iron
Weight of Cabinet 8KG
Brightness >1200cd/sqm
Density 160000dots/sqm
Best viewing angle 140 /120
Pixel Configuration 1R1G1B
Best viewing distance 4-30M
Maximum power consumption 1200W/sqm
Average power consumption 640W/sqm
Driving method 1/16scan
Control method Synchronization
Gray scale 65536
Colors 256*256*256
Color temperature 3200-9300k
Uniformity 97%
Working voltage AC220V/110V±10%
Working temperature -20ºC~+50ºC±10%
Working humidity 10% ~ 90%
MTBF 10,000 hours
Frame frequence 50/60Hz
Refresh frequence >1920Hz
IP grade IP30
Life Span 100,000 hours
Data transafer method RJ45
Pratical standard CCC TUV-CE ETL etc.
Effectivce Communication
Distance(without relay)
Unshielded twisted pair net line transmission distance:100M, max transmission distance:130M; Multi-mode optic fiber: 500M;
Single-mode optic fiber: 10KM
Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;HDMI,DVI,Composite Video;SDI,DP etc.
Systems operating platform WINDOWS(WINXP,WIN7/8/10), and interfaces for secondary development
