Commercial Touch Screen Kiosk Display , 32 Inch Capacitivedigital Lobby Signage
Commercial Touch Screen Kiosk Display , 32 Inch Capacitivedigital Lobby Signage
Specifications
Brand Name :
HBONY
Model Number :
HBY-D320
Certification :
CE CCC FCC ROHS ISO9001
Place of Origin :
Guang Dong
MOQ :
1 unit
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
300 Units per Week
Delivery Time :
5-8 work day
Packaging Details :
Inner Foam + honeycomb box +wooden case
Installation :
Wall mount
Panel size :
32inch (16:9)
Display area :
700x395.3
Touch screen :
Capacitive
Display Color :
16.7M
Operating Temperature :
0°C to 40°C
Panel :
Imported original LCD panel
TFT panel grade :
Grade A new panel
Description

HBONY 32inch Capacitive Touch Screen Digital Signage LED backlight

Strong Features
1 . Edge-to-edge glass IP65 rated
2 . 10-finger multitouch touch screen Panel
3 . Intel Celeron J1900 CPU, Intel HD Graphics
4 . 4GB RAM (expandable to 8GB)
5 . 64GByte SSD included
6 . 32Bit and 64Bit support, Linux and Win 7/Win 8/Win10 support
7 . Pre-installed Linux Ubuntu OS
8 . Consumer and industrial interfaces (Displayport, 3x-USB 2.0, 1x USB 3.0, 4-Serial RS232/RS485, VGA, 2x Gigabit-Ethernet, Optical Digital Audio Out, 8x programmable Digital Input-Output, screwable industrial power connector and many more)
9 . Integrated Wi-Fi (Intel 533AN), 2×10/100/1000 Mbps network ports
10 . Audio amplifier with 2x5w speakers
11 . VESA 100 bracket for mounting, metal stand included
12 . Customization available upon request

1,Touch screen parameters
Touch screen typeProjected capacity touch screen
Response time5ms
Touch pointsStandard 10-point touch
Touch recognition1.5mm(Finger, touch pen opaque objects)
Scanning rate200 Hz
Scanning accuracy4096×4096
CommunicationFull-Speed USB 2.0,3.0
Theory ClicksMore than 50 million times
Operating current / voltage180Ma/DC+5V±5%
Anti-light interferenceSunlight, incandescent, fluorescent and other light during normal use change
Touch data outputCoordinate output
Surface hardnessPhysical steel Mohs 7 explosion-proof glass
Operating System CompatibilityWindows 7/ Windows 8 / Windows XP / Linux /MAC OS /Android
DriveFree drive, plug and play
2,LED screen parameters


Screen Type


LED backlight, A-type

Resolution1920*1080P
Brightness350 cd
Contrast ratio5000:1
Response time5.5ms
Number of colors16.7M(8-bit 2(LVDS) Channel low-voltage differential signal)
Refresh rate60Hz
Viewing angle178 degrees horizontal,178 degrees vertical
Life time50000 hours


Commercial Touch Screen Kiosk Display , 32 Inch Capacitivedigital Lobby Signage
