Specifications
Pixel Pitch :
0.049RGB0.147 mm
Compliance :
RoHS
Operating Temp :
-20℃ ~ +70℃
Color Depth :
16.7M Colors
Certification :
CE, RoHS, ISO9001
Resolution :
360(RGB) × 360 Pixels
Screen Size :
2.1 inch
Brand Name :
Dingruishi
Viewing Direction :
All Angle
Supply Ability :
500,000pcs per week
Model Number :
DRS XC021
Display Mode :
Normally Black
MOQ :
100pcs
Packaging Details :
20cm * 30cm * 40cm
Pixel Arrangement :
RGB Vertical Stripe
Place of Origin :
Shenzhen, China
Payment Terms :
T/T
Price :
20-25USD
Delivery Time :
5-8 working days
Description

Product Overview


This integrated TFT LCD display module (XC021BWV9078ACT) is a fully assembled all-in-one display unit combining TFT panel, white LED backlight and drive circuits. Featured with 2.1-inch square screen and 360×360 high-definition resolution, it outputs 16.7 million true colors for excellent visual effects. Equipped with GC9B72NA professional display driver IC, the module supports multiple mainstream interfaces: MCU8bit, 3SPI, 4SPI, QSPI, MIPI 1lane and RGB 6bit, enabling seamless connection with most embedded MCUs and main controllers. The built-in white LED backlight has a 20,000-hour service life. The overall dimension is 66×66×3.31mm with compact layout, ideal for direct embedded installation without extra assembly work.
Key Hardware Specifications
  • Resolution: 480 × 480 pixels (square format with 16.7M color depth)
  • Driver IC: ST7701S (often uses RGB 24-bit + SPI interface)
  • Brightness: Typically between 450 - 550 cd/m² (nits) for crisp readability
  • Viewing Angle: IPS all-o'clock viewing (typ. 80° in each direction)
  • Operating Temp: -20°C to +70°C

Application FieldsEmbedded control systems,

smart home devices,

handheld terminals,

wearable electronics,

small industrial controllers.


Product Advantages

    • Fully integrated module, plug-and-play, no extra assembly required

      • 6+ optional interfaces, strong compatibility with mainstream controllers
      • Long-lifetime white LED backlight, stable brightness output
      • Ultra-slim 3.31mm thickness, suitable for space-limited enclosures
      • Square screen design, perfect for circular/square product casings
