2.1 360×360 LCD TFT SCREEN Raw TFT Panel
2.1 360×360 LCD TFT SCREEN Raw TFT Panel
2.1 360×360 LCD TFT SCREEN Raw TFT Panel
2.1 360×360 LCD TFT SCREEN Raw TFT Panel
2.1 360×360 LCD TFT SCREEN Raw TFT Panel
2.1 360×360 LCD TFT SCREEN Raw TFT Panel
Specifications
Supply Ability :
500,000pcs per week
Delivery Time :
5-8 working days
Color Depth :
16.7M Colors
Brand Name :
Dingruishi
Model Number :
DRS XC021
Certification :
CE, RoHS, ISO9001
MOQ :
100pcs
Price :
20-25USD
Resolution :
360(RGB) × 360 Pixels
Pixel Pitch :
0.049RGB0.147 mm
Payment Terms :
T/T
Screen Size :
2.1 inch
Display Mode :
Normally Black
Place of Origin :
Shenzhen, China
Pixel Arrangement :
RGB Vertical Stripe
Operating Temp :
-20℃ ~ +70℃
Viewing Direction :
All Angle
Compliance :
RoHS
Packaging Details :
20cm * 30cm * 40cm
Description

product Overview


This 2.1-inch raw LCD TFT screen D (XC021BWV9078ACT) is a standalone TFT glass panel designed for secondary assembly and screen replacement projects. Adopting Normally Black display mode and RGB vertical stripe pixel arrangement, it delivers 16.7M full-color performance with a standard 360×360 square pixel resolution. The raw panel features 0.049RGB0.147mm pixel pitch and supports all-direction viewing. Built with high-quality glass substrate, it works stably from -20℃ to +70℃ and stores safely at -30℃~+80℃. Compatible with mainstream TFT driver circuits, this bare TFT screen is a cost-effective choice for DIY assembly, electronic maintenance and customized screen refurbishment.

Application Fields

  • Electronic device maintenance,

    DIY circuit assembly,

    small consumer electronics,

    portable gadgets,

    screen replacement projects.

Product Advantages

      • Pure raw TFT panel structure, easy for secondary processing and assembly
      • All-direction viewing angle, clear visuals from all perspectives
      • Wide temperature tolerance for indoor and semi-outdoor use
      • 16.7M rich colors for vivid image presentation
      • RoHS certified, eco-friendly for global sales
