High Resolution Monochrome LCD Display 128x128 50 Pins FPC
High Resolution Monochrome LCD Display 128x128 50 Pins FPC
High Resolution Monochrome LCD Display 128x128 50 Pins FPC
High Resolution Monochrome LCD Display 128x128 50 Pins FPC
Specifications
Place of Origin :
China
Brand Name :
BBI
MOQ :
1000
Price :
0.1-5USD
Packaging Details :
CARTON
Delivery Time :
20-30DAYS
Payment Terms :
T/T D/P Paypal
Supply Ability :
5000000/months
Certification :
ISO9001,RoHS,CE,REACH,SGS
Name :
Monochrome LCD Display
Operating Temp :
0~+50°C
Display Color :
Black
Dot :
128*128
Lcd Drive Voltage :
5.0V
Display Backgrountnd :
gray
Fpc Pin Number :
50 Pins
Description

High Resolution Monochrome LCD Display 128x128 50 Pins FPC

General Specification:

1: Application:

Display Type : HTN .

Display Mode: Positive .

Polarizer Mode: Transflective .

Driving Method:Vop 3.0 ,Duty 1/4,Bias 1/3 .

Viewing Direction: 12 o’clock .

Display Color: Display Pixel: Black .(On Stage, Pixel Color)

Back Ground: gray .(Off stage,Display Color)


2: Dimensional outline and display pattern


Item

Specifications

Unit

Dimensional Outline

99.00±0.20(L) X 43.00±0.20(W) X 2.80(MAX)

mm

Viewing Area

98.00(L)MIN X 39.50(W)MIN

mm

PIN Pitch

2.54

mm

PIN Length

6.35

mm

Number of PIN

36

-----

3. Absolute maximum ratings

No.

Item

Characteristic values

Unit

Remark

Min.

Typ.

Max.

1

Operating temperature range

0

----

50

°C

2

Storage temperature range

-10

----

60

°C

3

AC voltage

----

----

10

V

1hr

4

DC voltage

----

----

3

V

1hr

5

Tolerable DC component

----

0

30

mV

6

Tolerable atmospheric pressure

86

----

106

kPa

7

Tolerable vibration

----

0

50

m/s2



4. Electro-optical characteristics

Item

Symbol

Measurement

temperature

Min

Typ.

Max.

Unit.

Remark

Note

Operating voltage

Vop

25°C

3.0

V

(1)

Response

Time

Rise time

Tr

25°C

---

100

150

ms

Vop= V

(2)

Decay time

Td

25°C

---

100

150

Current consumption

(all seg on)

Iop

25°C

---

---

1

μA

/cm2

(3)

Contrast ratio

Cr

25°C

2

--

---

---

Vop= V

(4)

Frame frequency

f

32

64

128

Hz

(1)

Capacitance

(all seg )

C

25°C

---

---

2

nF/cm2

(5)

Viewing angle

q

25°C

0

---

40

Deg

F=180°

(6)

q

25°C

0

---

30

Deg

F=270°

q

25°C

0

---

30

Deg

F=90°
