Specifications:

1.Display Mode: FSTN/Transflective/Positive.
2.Viewing Angle: 6 0'clock.

3.Drive Method:1/64 Duty,1/9 Bias
4.Top: -20°C~+70°C

Tst: -30°C~+80°C.
5. Connector: COG+FPC.
6. Drive IC: ST7567A

Primary Application Areas

1.Industrial Control

Equipment status display

Instrumentation panels

2.Consumer Electronics

Portable device displays

Home appliance interfaces

3.Medical Devices

Portable medical instruments

Basic diagnostic devices

4.Transportation Systems

Shared device lock screens

In-vehicle information terminals

5.Retail & Payment

POS systems

Electronic shelf labels

6.Communication Devices

Walkie-talkie status screens

Network equipment indicators

FAQ

1.Can small-sized LCD screens be equipped with touch functions?

Yes. This is a very common requirement. The touch panel is typically laminated onto the surface of the LCD. Main types:

Resistive Touch: Low cost, resistant to surface contaminants (dust, water), works with any object. Lower transmittance, relatively less durable (scratches), usually no multi-touch.

Capacitive Touch: High transmittance, sensitive and smooth touch, supports multi-touch, durable (glass surface). Higher cost, requires finger or special stylus, sensitive to water/oil on surface.

2.How long is the lifespan of a small-sized LCD screen?

Lifetime primarily refers to the Backlight lifespan (usually measured in hours until brightness drops to 50% of initial) and the reliability of the LCD Panel itself.

Backlight Lifetime: Common LED backlights typically last 30,000 to 70,000 hours (approx. 3.5 to 8 years of continuous use). High temperatures significantly reduce this.

LCD Panel Lifetime: Generally very long, often 50,000 hours or more under normal operating conditions (avoiding physical shock, extreme temperatures, excessive humidity). The screen itself typically does not suffer from "burn-in".

3.How long does it usually take for a sample?

Samples usually take 3 to 5 days to be dispatched

4.How long is the delivery cycle generally?

The delivery time is within 20 to 30 days
