Metal DC 12V 23 Inches Strip 350 Nits Stretched Bar LCD
Metal DC 12V 23 Inches Strip 350 Nits Stretched Bar LCD
Metal DC 12V 23 Inches Strip 350 Nits Stretched Bar LCD
Metal DC 12V 23 Inches Strip 350 Nits Stretched Bar LCD
Metal DC 12V 23 Inches Strip 350 Nits Stretched Bar LCD
Metal DC 12V 23 Inches Strip 350 Nits Stretched Bar LCD
Metal DC 12V 23 Inches Strip 350 Nits Stretched Bar LCD
Metal DC 12V 23 Inches Strip 350 Nits Stretched Bar LCD
Metal DC 12V 23 Inches Strip 350 Nits Stretched Bar LCD
Metal DC 12V 23 Inches Strip 350 Nits Stretched Bar LCD
Specifications
Brand Name :
Skyvision
Model Number :
WM2200WS
Certification :
CF, FCC, ROHS
Place of Origin :
China
MOQ :
10
Price :
US$140-US$168
Payment Terms :
T/T, Western Union
Supply Ability :
5000 unit per 5 weeks
Delivery Time :
3 to 35 working days subject to order quantity and requirement
Packaging Details :
inner box+EPE foam+master box
Multimedia :
video playback, slide show, music, timer on/off, clock+date
In/output :
SD card slot, USB, Audio-out, HDMI in is optional
Application :
Indoor
Brightness :
350nits
Input voltage :
DC12V
Viewing angle :
178/178(H/V)
Max resolution :
1920*158
Warranty :
12 Months
Panel size :
23 inches
Color :
Black
Material :
metal
Description

Item name: 23 inches Strip LCD monitor
Dimension of outter frame 597.4*60.4*15 mm
Color & casing materials Metal with black matte paint
Display Panel 23" LCD panel with low consumption LED backlight
Resolution 1920x158px. ( display area: 585.6(H) * 48.19(V)mm )
Aspect Ratio to be advised
Visual angle 89°/89°/89°/89°
Luminance 350 cd/m2 　 　 　 　 　
Contrast 1500:1
Hardware PCB (mother board) Mstar 59
multimedias: video, slide show, music, video+photos, photos+music, clock+calendar
others: playing as per re-setup play list, timer play, auto-copy, timer on/off, power off memory etc.
Interface SD Card slot Yes x 1(Max. support 32GB SD card)
HDMI in Yes x 1 (1280x720px. And 1920x1080px. FHD input)
USB Host 2.0 Yes x 1
DC power input Yes x 1
Sound System Speaker Yes, 2 pieces x 5W
Video Video format dat, vob, avi, mp4, mpg, ts, trp, mov, mkv (MPEG1/2/4, DIVX, H264,)
max. decoding 1920x1080px. videos ( Max. 30 frm /s, 30 Mb /s, 24 bit)
Music Music format mp3, wma, m4a, acc (max. 32 kbps ~ 384 kbps)
Photo Photo jpg, jpeg, bmp, png
Other .txt
　 Photo playback speed adjustment interval setup
OSD Languages OSD Language English, other languages are customizeable for bulk order
Others Power consumption about 18W
Push buttons None
Accessories Power adapter PSE standard, AC input 110V-240V, DC output 12V 2A
Remote control Yes
Wall mounting bracket optional
