3.5 Inch TFT LCD Module 320x240 Resolution 50pin FPC

Specifications

MOQ :

500

Price :

Model NO. :

RY015

Aspect ratio :

4:3

Optimum Resolution :

320*240

Type :

TFT

Response Time :

25ms

Interface Type :

RGB

Resolution :

800X3(RGB)X480

Module Size :

126.5 X 100.0 X 5.7 mm

Active Area :

112.896 X 84.672 mm

Viewing Angle :

50/70/70/70

Interface :

50pin FPC, Parallel 24bit RGB

Screen Size :

3.4 inch

Luminance :

200 nits

Contrast Ratio :

500

Weight :

127.5 g

Description

OEM Original Innolux 3.4 inch TFT LCD Module display

Innolux's employees worldwide number more than 60,000, and its production sites and sales locations span the globe.
With its major TFT plants located in Zhunan and Tainan, both in Taiwan, Innolux has also established overseas
module plants in the Chinese cities of Ningbo, Nanjing, Foshan, and Shanghai. Innolux's extensive global presence allows it to quickly provide a full range of services to its customers, reducing logistics and manpower costs, while achieving the environmental objectives of energy conservation and reduced carbon emissions. Innolux's unique intelligent management platform has not only enhanced the company's management capabilities, but also provides customers with prompt, accurate delivery information. This is just one of the ways we are constantly striving to boost customer satisfaction.

Product Description

Item	Description
Model Name	AT056TN52 V.3
Product type	LCD Module
Screen Size	3.4"
Aspect Ratio	4:3
Resolution	800X3(RGB)X480
Module Size(mm)	126.5 x 100.0 x 5.7
Active Area(mm)	112.896 x 84.672
Viewing Angle (Tpy.)θT/θB/θL/θR	50/70/70/70
Luminance(nits)	200
Contrast Ratio	500
Response Time(ms)	25
Weight (g)	127.5
Interface	50pin FPC,Parallel 24bit RGB
Operation Temperature( ºC)	-20º C~70ºC
Storage Temperature (ºC)	-30º C~80ºC
HTHH.(op)	40ºC 90%RH 240h
