STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective
STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective
STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective
STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective
STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective
STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective
STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective
STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective
Specifications
Brand Name :
ROYAL DISPLAY
Model Number :
RY-C204LYILYW
Certification :
ISO Rohs
Place of Origin :
CHINA
MOQ :
500pcs
Price :
Negotiable
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
300k/Month
Delivery Time :
25~28 Working Days
Packaging Details :
Standard Packaging
Display Type :
20(Characters) *4(Line)
LCD Type :
Stn Yg/Blue, Transflective, Positive1/16duty, 1/5b
Backlight Color :
Yg/Blue
View Area(mm) :
76.0*25.4
Display Area(mm) :
70.41*20.81
Dots Size(mm) :
0.56*0.56
Dots Pitch(mm) :
0.60*0.60
Drive IC :
Splc780d1-021A
Description

2004 Character STN Yg/Blue LCD Display Monochrome COB LCD Module

PRODUCT DESCRIPTION

1. 20x4 Characters
2. STN-YG, STN-blue, FSTN-Gray, FSTN-Positive display results as option

Item Description
Product Name STN YG/Blue 2004 LCD Display Module
Model No. RY-C204LYILYW
Display Type 20(characters) *4(line)
View Area(mm) 76.0*25.4
Display Area(mm) 70.41*20.81
Interface 8-bits MPU interface
Power supply 5V
Operating Temp -30º C~80ºC
Storage Temp -40º C~90º C

STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective

APPLICATION

More than 90% of our products is specially customer designed to be used in Video and Audio system, financial, medical, industry equipment, testing devices, Electronic meters, facsimiles, many kinds of terminal equipment and so on. With the capability of 300K different kinds of LCM/LCD per month.

STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective

FAQ

1. Q: Order process
A: PO is placed by clients → PI is issued by Royal Display → Payment by clients → Lead time is confirmed by Royal Display → Shipping instrction by Clients → Delivery → Cargo tracking → Receipt of cargo

2. Q: Lead time ( after payment is confirmed)
A: Sample: 1-10 working days Volume: 3-60 working days

3. Q: Payment
A: T/T , Western union, L/C, Credit card, and Cash

4. Q: Warranty
A: 12 months warranty ( Please find more details via our datasheet by item of Limited Warranty)

5. Q: RMA Process
A: Claimed by cliens with photos or videos → Sales rep of Royal Display confirm if have questions → Sales rep issue RMA No to clients if confirmed by QA → Return to Royal Display → Formal report after goods received by Royal Display → Clients confim the analysis report → Proceeding as per the Report both agreed

6. Q: Notes
A: Please check both appearance and function of products prior to installation.
Any damage caused by improper use or unprofessional installation is not covered under warranty.

STN Yg COB LCD Module MPU Monochrome Matrix Segment Transflective
