Specifications
Brand Name :
ORIENTRONIC
Place of Origin :
China
MOQ :
First purchase, no purchase quantity limit.
Price :
Prices are set based on design and quantity.
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, Paypal
Supply Ability :
200K Sets / Month
Delivery Time :
4~6 Working Days
Packaging Details :
Prices are set based on design and quantity.
Size :
1.28-inch IPS LCD
Material :
TFT LCD
Resolution :
240 (RGB) X 240
Touch type :
Capacitive touch Communication
interface :
8-bit parallel port
Operating voltage :
3.3V
Driver chip :
GC9A01
Touch chip :
CST8165
Display color :
Full color
Module dimensions :
39 (H) x 40 (V) x 4.98 (D)
Display area :
Ø32.4
Pixel pitch :
0.135 (H) × 0.135 (V)
Viewing direction :
Full perspective
Backlight :
2 CHIP White LEDs
Working current :
20mA
Pin count :
Plug-in type (20-pin FPC ribbon cable with 0.5mm pitch)
Working temperature :
-20 to 70 degrees Celsius
Description

1.28-inch TFT display screen

1.28-inch TFT LCD display, IPS screen, circular display, capacitive touch screen, GC9A01 driver,segment lcd display,segment lcd

Structural drawing

1.28-inch TFT LCD display, IPS screen, circular display, capacitive touch screen, GC9A01 driver,segment lcd display,segment lcd

Module interface definition

NO. Symbol Description
1 GND

Power Ground
2 VCC-3.3V

Power Supply for I/O system.vcc=3.3v
3 BLK Backlight control
4 CS Chip selection pin,Low enable ,High disable
5 RESE Display data/command selection pin
6 DC Write enable in MCU parallel interface
7 WR Read MCU parallel interface
8 RD MCU parallel interface data
9 DB0 MCU parallel interface data
10 DB1 MCU parallel interface data
11 DB2 MCU parallel interface data
12 DB3 MCU parallel interface data
13 DB4 MCU parallel interface data
14 DB5 MCU parallel interface data
15 DB6 MCU parallel interface data
16 DB7 MCU parallel interface data
17 TP_INT External interrupt to the host
18 TP_SDA 12C data input and ouput
19 TP_SCL 12C data clock input
20 TP_RST This signal will reset the TP,signal is active low.
