110 Anti Glare Glass 4K Resolution Android PC All In One Touch Screen Smart Board for School Meeting Room
110 Anti Glare Glass 4K Resolution Android PC All In One Touch Screen Smart Board for School Meeting Room
110 Anti Glare Glass 4K Resolution Android PC All In One Touch Screen Smart Board for School Meeting Room
110 Anti Glare Glass 4K Resolution Android PC All In One Touch Screen Smart Board for School Meeting Room
110 Anti Glare Glass 4K Resolution Android PC All In One Touch Screen Smart Board for School Meeting Room
110 Anti Glare Glass 4K Resolution Android PC All In One Touch Screen Smart Board for School Meeting Room
110 Anti Glare Glass 4K Resolution Android PC All In One Touch Screen Smart Board for School Meeting Room
110 Anti Glare Glass 4K Resolution Android PC All In One Touch Screen Smart Board for School Meeting Room
Specifications
Brand Name :
GENEVISION
Model Number :
MAD-1100
Certification :
CE, FCC, ROHS, CCC
Place of Origin :
CHINA
MOQ :
1PC
Price :
USD5000 - USD6000 / PC
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3000 set /month
Delivery Time :
10 working days
Packaging Details :
Carton
Keyword :
Dual Screen touch screen smart board
AG glass :
Yes, 4mm thickness anti glare glass
Resolution :
3840*2160
Camera and microphone :
On option
Touch points :
40 points
OPS :
Optional
Screen size :
55inch, 65inch, 75inch, 85inch, 86inch, 98inch and 110inch
System :
Android 13.0 or 14.0
Description

55" 65" 75" 85" 86" 98" and 110" Anti Glare Glass 4K Resolution Android PC All In One Touch Screen Smart Board for School Meeting Room

Quick details of touch screen interactive flat panel :

1. Hotsale size is 55 inch, 65 inch, 75 inch, 85 inch, 86inch, 98inch and 110inch.

2. 40 points multi touch screen.

3. Camera and microphone on option.

5. 2pc 10W larger power speaker, also support connect to external speaker and sound system.

6. AG glass in front.

7. 4K resolution, 3840*2160.

8. Android 13.0 system inbuilt, 4G+32G, support google play.

9. Can be with OPS Windows system: CPU can be i3, i5, i7, from 4th to 15th, RAM can be DDR3/4 4G, 8G, memory can be 32G or 128G.

10. Have CE, ROHS, CCC, RCM, FCC certificates.

Specification of touch screen interactive flat panel :

Active Display Area 2436mm(H)×1370mm(V)
Aspect Ratio 16:9
Visual Angle Horizontal178/Vertical178
Panel CSOT, BOE, etc., A Level
Brightness 400cd/m2
Contract Ratio 4000:1
Resolution Ratio 3840*2160
Color Components 8 Bit+ FRC,1.07G Colors
Refresh rate 60HZ
Response Time 8ms
Power Consumption 450W
Standby power consumption ≦0.5W
Glass 3mm thickness standard AG tempered glass
Touch screen spec IR 40-point touch screen, Interpolation Resolution: 32768 x32768,Touch Accuracy:90% Central Area:±2mm,Touch Height:3mm,Response Time:4~11ms,Output Mode:HID Standard,Theory Clicks:Infinite,Minimum Touch Object:2 points ≥ 3mm / multi points ≥ 5mm,Connect Type:Full Speed,Voltage:DC 5V±5%,Power Consumption:≤1W
Speaker 8Ω 10W*2pc
Power Supply Input:AC110-240V-50/60Hz
Color of Shell Dark grey
Life of Panel 60000Hours
Tablet and Smart phone wireless screen sharing (miracast by software) Support, cost extra
Dimension of Machine L2590xH1590xW141mm
Carton box packing 2660*300*1660mm, G.W.: 148KG
Photo formats JPG, JPEG, BMP, PNG etc.
Audio formats MPEG1/2 layer I/II,AC-3(To be customized),AAC-Lc,WMA…
Video formats MPEG2-4,H.264,H.265,TS, Realmedia, etc.
OSD Language English, Chinese, Arabic etc.
Working Temperature/ Hulmidity -10℃-50℃ / 10%RH~90%RH
Storage Temperature/ Hulmidity -20℃-60℃ / 10%RH~90%RH
Accessory Wall mount*1,Power Cord*1,Remote Control*1,Touch Pen*2,Qualified Certificate label*1,Warranty Card*1
Front port USB 3.0*2 , HDMI in*1, Touch *1, Type C*1
Other function
Smooth writing Smooth writing experience, touch delay <8MS
Touch menu Touch on the screen through gestures to achieve menu, signal source switch, sound, brightness and other functions control
Intelligent signal switching Connect and input the signal, the device will automatically identify and switch to the corresponding video signal source channe
Gesture wipe function Wipe text and patterns on the screen with gestures
Two-way control function Touch the screen to control the computer, convenient and fast
Wireless screen transfer function No need to plug in the cable, you can project the content on the computer to the screen (optional)
Zoom in, zoom out, drag Using multi-touch technology, picture zoom in/out arbitrarily, and move the picture freely
Android Mainboard Configuration
CPU T982-N0DN, Cortex A55*4, Mali-G52 MP2 (2EE)
RAM DDR3 4G
Memory 32G
OS Android 13.0, support Google play
Bluetooth 5.0
Wifi 2.4G and 5.0G
Side view port USB3.0*1,USB2.0*1,HDMI IN*2,TOUCH*1,LINE OUT*1,RJ45*1
Bottom view port MIC*1,RS232*1,OPTICAL*1,VGA IN*1,AUDIO IN*1
OPS Configuration
CPU i3-4th
Memory DDR3 4G
SSD 128G
OS Windows10 Pro
Wifi M.2 PCIe 2230
JAE Connector Type-c SUPER IO 1 JAETX25
Input Port RJ45 in*1, USB3.0*2, USB2.0*4, Mic in*1
Output Port HDMI out*1, VGA out*1, Line out*1, Audio out*1


Application of touch screen interactive flat panel :

This touch screen smart board can be used in school, meeting room, exhibition center, office, also the smart interactive flat panel can be used in eudcation institutes.
