OEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCC
OEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCC
OEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCC
OEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCC
OEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCC
OEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCC
OEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCC
OEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCC
Specifications
Brand Name :
LONGYU
Model Number :
DIPA150C
Certification :
CE Rohs
Place of Origin :
China
MOQ :
1PCS
Price :
TBA
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
10000PCS/Month
Delivery Time :
7-10 Work Days
Packaging Details :
1-5pcs/CTN, Safe, Firm, suitable for international shipping
CPU :
Intel®Celeron™ J900
USB :
1x USB3.0/3 x USB2.0
system :
Windows7, Windows10, Linux
Brightness :
350 cd/cm²
Screen :
15.0" Full HD TFT
Angle of view :
(L) 80/ (R) 80 / (T) 80 / (B) 80
Working tempetature :
0 ~ 50° C (32~113°F)
Operating Temperature :
-20 ~ 60° C (-4 ~ 140°F)
Description

OEM 15 inch Tablet 1024*768,10 point touch Windows10 Linux X86 IPC

system parameter

CPU

Intel®Celeron™ J900

frequency

2.0GHz

Running memory

Support DDR3L-1333 MHz, 1 * SO-DIMM Slot, Up to 8GB

EMMC

1 * mSATA(3.0)

I/O port

network

2*Realtek® 1Gbps PCIe Ethernet Controller, RJ-45以太网接口

Mic

Realtek® HDA Codec, with MIC/Line-out

USB

1x USB3.0/3 x USB2.0

Serial port

4 x RS-232； 2 x RS-232 / RS-485

expansion slot

1 * SATA3.0 7+15P Connector/2*Mini-PCIe (1*mSATA, 1*Wifi+4G)

I/O port

1 x VGA / 1 x HDMI/2 x GLAN / 4 x USB / Line-out / Mic-in/DC-IN

Dimension (W x H x D)

361mm x285mm x 52mm

hole size (W x H)

346mm x 272mm

Net Weight

3.56kg

Operating System

Operating System

Windows7, Windows10, Linux,

Power

Input voltage

12VDC (12-24VDC)

MaximPower Consumption

25W

Display

screen

15.0" Full HD TFT

Resolving power

1024×768

Color Dispay

16.7MB

Backlight

LED

Backlight life

50000hrs

Pixel pitch

0.297×0.297

Luminance

350 cd/cm²

Contrast

700 : 1

View angle

(L) 80/ (R) 80 / (T) 80 / (B) 80

Environmental parameter

Working temperature

0 ~ 45° C (32~113°F)

0 ~ 50° C (32~113°F) ；-20 ~ 60° C (-4 ~ 140°F) (RT)

Operating Temperature

-20 ~ 60° C (-4 ~ 140°F)

Relative humidity

10~95% RH@40°C,non-condensing

Vibration

SSD applied: 1.5 Grms, 5 ~ 500 Hz, 1 hr/axis

EMC

CE/FCC Class B

waterproof

IP65

OEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCCOEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCCOEM 10 Point Touch Tablet TFT IP65 15 Inch Panel PC Windows10 Linux X86 IPC FCC
