Specifications
Brand Name :
Junxian or Customizable
Model Number :
JM-PT106-00
Certification :
ROHS
Place of Origin :
China
MOQ :
5 sets
Price :
Negotiable
Payment Terms :
L/C,T/T,Paypal
Supply Ability :
200000 pieces per month
Delivery Time :
1-4 weeks
Packaging Details :
Standard Exportation Package
Name :
Round TFT LCD Display
LCD Interface :
RGB
Resolution :
240×240 Pixels
LCD Size :
41.5mmx41.5mmx3.09mm
Visual Area :
35.60mmX37.74mm
Surface Luminance :
350cd/m2 up to 400 nits (cd/m²)
Control driver :
GC9A01
Display Type :
IPS
Touch Screen: :
Without Touch Screen (Customizable)
Display Color :
16.7M
Backlight :
LED white light
LED Lifetime :
40,000 hours
Description

1.28 Inch Round TFT LCD Display Custom touchscreen Lcd Panel HD Lcd Display For Wearables Tech

1. Product Features and Advantages
1.1 Compact and High - Resolution Design
This is a 1.28 - inch round TFT LCD display. It features a crisp HD resolution of 240×240 on an IPS panel, which provides wide viewing angles and sharp imagery in all orientations.
1.2 Advanced Interaction Capability
Equipped with a responsive PCAP (Projected Capacitive) touchscreen, enabling intuitive user interaction.(For the same model, the version without a touch screen is optional.)
1.3 Customizability
The cover glass dimensions are customizable to fit device design requirements, allowing for better integration into various products.
1.4 Flexible Connectivity Options
It has a default SPI interface, with the option to customize the protocol, which makes it adaptable to different system setups.
1.5 High - Performance Display in Different Lighting
With an adjustable brightness up to 400 nits (cd/m²), it offers sunlight - readable performance, ensuring clear visuals in various lighting conditions.
1.6 Long - lasting Durability
The LED has a lifespan of 40,000 hours, making it suitable for continuous operation in rigorous environments.
1.7 Environmental and Safety Compliance
Meets REACH and RoHS directives, which means it is environmentally friendly and safe for occupational use.
2. Product technical parameters
Keywords: 1.28-inch TFT color LCD
Resolution: 240×240 Pixels
LCD Interface: RGB
LCD Size: 41.5mmx41.5mmx3.09mm
Visual Area: 35.60mmX37.74mm
Control driver: GC9A01
CTP Interface: None
Surface Luminance: 350cd/m2
Touch Screen: Touch-screen and No Touch screen for optional
Operating Temp: -20℃～＋70℃
Storage Temp: -30℃～＋80℃
Display Type: IPS
Contrast Ratio: 1-100%
Driving voltage: 3.1V
LED Lifetime: 40,000 hours
Backlight: LED white light
Display Color: 16.7M
Certificate: GB/T19001-2016/IS09001:2015
Compliance: REACH & RoHS Compliant
3. Product in details:

1.28 Inch Round TFT LCD Display Custom Touchscreen LCD Panel 240×240 Pixels HD LCD Display

1.28 Inch Round TFT LCD Display Custom Touchscreen LCD Panel 240×240 Pixels HD LCD Display

This 1.28 - inch TFT Color LCD is Your Ideal Display Solution!

If you have specific requirements beyond the standard features, Please feel free to contact us,we are more than happy to assist. We accept customized services and OEM processing.Just provide us with relevant drawings, and our professional team will work with you to create a display solution that perfectly meets your unique needs.

4. Application fields of 1.28 Inch LCD dispalys

Wearable Tech‌: Smartwatches, fitness trackers, medical wearables.

‌IoT Solutions‌: Smart sensors, portable diagnostic tools, home automation panels.

‌Industrial HMI‌: Machine interfaces, ruggedized control systems, field equipment displays.

Here are some expand the application areas of LCD liquid crystal displays:
  • Automotive: Applied in car dashboards, navigation systems, and rear - view monitors.
  • Medical: Utilized in medical monitors, ultrasound machines, and electronic medical records.
  • Industrial: Employed in industrial control panels, instrument displays, and factory automation systems.
  • Public Display: Seen in digital signage, billboards, and information kiosks.

​

Why Choose JUNXian?

Founded in 2005, Junxian is a leading LCD display manufacturer. Our team of seasoned engineers and professionals offers a comprehensive range of LCD products. We also provide customized solutions for LCDs and touchscreens tailored to your unique needs.

1.28 Inch Round TFT LCD Display Custom Touchscreen LCD Panel 240×240 Pixels HD LCD Display

1. Direct source factory, professional team, and competitive prices
Our own factory ensures both the product quality and production speed,We can provide quick prototyping to speed up your product development process. Our technical support team is always ready to assist you, ensuring a smooth experience from design to implementation.

1.28 Inch Round TFT LCD Display Custom Touchscreen LCD Panel 240×240 Pixels HD LCD Display

2. Custom LCD Displays & CTP-Integrated Modules

With 20 years of manufacturing excellence, we specialize in crafting custom LCD displays—ranging from 0.96" to 15.6"—including models with fully integrated capacitive touch panels (CTP). Our professional capabilities enable end-to-end customization of critical components: FPC cables, backlight materials, and PCBA, ensuring seamless alignment with your technical specifications.

1.28 Inch Round TFT LCD Display Custom Touchscreen LCD Panel 240×240 Pixels HD LCD Display

3.Stringent Quality Control
Robust quality control processes at every stage—from raw materials to final inspection—guarantee superior performance and durability.

1.28 Inch Round TFT LCD Display Custom Touchscreen LCD Panel 240×240 Pixels HD LCD Display

4. Certificates and Honors

We hold the GB/T19001 - 2016/IS09001:2015 certificate, ensuring that the quality of every product exceeds industry standards.

1.28 Inch Round TFT LCD Display Custom Touchscreen LCD Panel 240×240 Pixels HD LCD Display

5. Rapid Delivery & Global Service
Streamlined workflows and flexible production enable quick order turnaround, supported by a worldwide logistics network.

With 20 years of expertise, we're not just suppliers! JUN Xian is your partners in innovation.

Contact us now to get custom LCD solutions, quick samples, and expert support, and let’s bring your vision to life!

Please Note

All photos on this site are authentic. However, due to variations in lighting, shooting angles, and display resolutions, slight chromatic aberration may occur. Thank you for your understanding.
We support product Customized Service and OEM& ODM service. Please contact our professional customer service team before placing an order to confirm product specification in details.
