7.0-inch is an RGB interface, TFT, TN 6 0'Clock is ultra-wide view, resolution of 800 * 480 LCD TFT Display
7.0-inch is an RGB interface, TFT, TN 6 0'Clock is ultra-wide view, resolution of 800 * 480 LCD TFT Display
7.0-inch is an RGB interface, TFT, TN 6 0'Clock is ultra-wide view, resolution of 800 * 480 LCD TFT Display
7.0-inch is an RGB interface, TFT, TN 6 0'Clock is ultra-wide view, resolution of 800 * 480 LCD TFT Display
7.0-inch is an RGB interface, TFT, TN 6 0'Clock is ultra-wide view, resolution of 800 * 480 LCD TFT Display
7.0-inch is an RGB interface, TFT, TN 6 0'Clock is ultra-wide view, resolution of 800 * 480 LCD TFT Display
Specifications
Brand Name :
HG
Model Number :
HG070WV026
Certification :
ROHS/CE/ISO9001
Place of Origin :
ShenZhen China
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
350KPCS/Mouth
Delivery Time :
7-15working days
Packaging Details :
Standard Export Package
Product Name :
7.0-inch LCD TFT display
LCD Type :
TFT
Dot Arrangement :
800*480
Viewing Angle :
TN 6 O'clock ultra-wide view
Luminance :
1000cd/m2(customizable）
Signal Type :
RGB Interface 50PIN
Description

HG070WV026: 7.0-inch is an RGB interface, TFT, TN 6 0'Clock view, display effect is ultra-wide view, resolution of 800 * 480 LCD TFT display, suitable for outdoor industrial control equipment, can be visible in the sun .

Product parameter details

Model HG070WV026 Application industry outdoor industrial control
Size 7.0 inch Arrangement 800*480
Display size 154.08mm*85.92mm External dimensions 164.9mm*100mm*5.7mm
Viewing Angle

TN 6 O'clock

ultra-wide view

 Luminance 1000cd/m2(customizable)
Contrast ratio 500 NTSC 45%
Signal types RGB Interface 50PIN
Temperature Operating temperature in: -20℃ ~70℃, storage temperature: -30℃ ~80℃

Remark

 Standard series of LCD TFT displays, highlighting products, visible in the sunlight

Description of products

HG070WV026 is a standard series highlighter with a resolution of 800*480 and an ultra-wide viewing Angle

LCD TFT display,

It consists of a TFT LCD panel, driver IC, FPC, and backlight source (upper and lower EWV)

Using RGB-24 channel interface 50PIN, can work in -20℃~70℃, storage temperature: -30℃~80℃

This product is widely used in industrial control, medical, handheld, security, vehicle, instrumentation and other related products

All products are available with or without touch and industrial drive boards, no matter what configuration you choose,

Can be customized according to your requirements (can be customized backlight, FPC, touch screen, industrial drive board)

It also meets RoHS and CE certification standards

If you can't find a suitable one, please contact us for a recommendation.

7.0-inch is an RGB interface, TFT, TN 6 0'Clock is ultra-wide view, resolution of 800 * 480 LCD TFT Display

Packaging and transportation

Packaging details:

1.All products are packaged correctly to ensure safety.

2.For small-size products, we use the tray = carton.

3.For larger sizes, we use knife cards + foam + cartons.

4. We can also design packaging according to customer requirements.

Transport:

1. Through express delivery (3-7 working days),

2. Marine transportation (15-30 days), suitable for conventional mass production.

3. Air transport (4-5 days), from airport to airport.
