Smooth Lining Agricultural Irrigation Pipe / High Pressure Layflat Hose For General Watering
Smooth Lining Agricultural Irrigation Pipe / High Pressure Layflat Hose For General Watering
Specifications
Brand Name :
ASOE
Model Number :
Manureflow Drag
Certification :
ISO
Place of Origin :
China
MOQ :
10cm
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, D/A, D/P, MoneyGram
Supply Ability :
10000m per week
Delivery Time :
depends on your order quantity
Packaging Details :
Standard Export Package, carton, container, non woven fabric, plastic film, wooden case
Product Name :
Agricultural Hose
Feature :
Ultimate Tensile Strength, Ultimate Elongation, Accelerated Aging Test
Working pressure :
9bar- 13bar , 135psi - 190 psi
Size :
4inch to 7inch
Sample :
Available
Usage :
irrigation, agriculture, general watering, dewatering, drainage, pump discharge
Description

1.5 8 12inch Agricultural Hose / Farm Hose / Agricultural Tubing and Assemblies

MANUREFLOW PU DRAG HOSES shall be made from 100% high tenacity synthetic yarn circular woven and completely, totally embedded in the PU compound. The inner tube and cover are smooth PU cover and tube. The reinforcement is circular woven polyester jacket. The operating temperature range is from -60° F to 176° F(-50° C to 80° C). The standard color is red, olive green, other colors available per request. The standard lengths are 660ft/200m; 990ft/300m, 1320ft/400m, other lengths available per request. The couplings are aluminum LDHC agro couplings. The warranty is 5 years. guarantee

Advantages

♦ Very smooth lining for friction loss
♦ Ultra-high tensile strength to avoid breaking
♦ Greatly high abrasion and punctuation resistant
♦ Extremely high adhesion strength to avoid peeling
♦ Superior kink resistant for max hydraulic efficiency
♦ Low operating cost with long service life


Applications

Agriculture and mining
Transport of abrasive materials
Flexible pipeline even in extreme terrain
Iirrigation and sludge disposal
Supply hose for liquid manure and sludge injection systems
For heavy duty service under toughest conditions

Features

Superior abrasion resistance
Extremely hardwearing and durable for long service life
Ultra-high tensile strength
Resistance to oil, fuel and a wide range of chemicals (see resistance table in technical appendix)
Resistance to weathering, UV and ozone
Lightweight and easy to handle compared to material handling hose in rubber
Excellent cold flexibility

Comparable to:

Dragman of Mandals
Dragmaster of Angus
Hilcoflex PU drag of G&H

Color

Red/Orange/Black/Blue (Other color available of request)

Manureflow™Drag PU Layflat Hoses
ID
Wall Thickness
Weight
Working Pressure
Bursting Pressure
Inch
mm
Inch
mm
lbs/ft
kg/m
PSI
Bar
PSI
Bar
4
103+2.0
0.14
3.6
0.94
1.4
190
13
560
39
5
128+2.5
0.16
4
1.21
1.8
190
13
560
39
5.5
141+2.5
0.16
4
1.41
2.1
150
10
450
30
6
153+2.5
0.17
4.2
1.48
2.4
150
10
450
30
7
178+3.0
0.17
4.4
1.92
2.86
135
9
105
28
