SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe Bar Feeder High Efficiency Turning Machine for Automotive Parts Production
SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe Bar Feeder High Efficiency Turning Machine for Automotive Parts Production
SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe Bar Feeder High Efficiency Turning Machine for Automotive Parts Production
SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe Bar Feeder High Efficiency Turning Machine for Automotive Parts Production
SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe Bar Feeder High Efficiency Turning Machine for Automotive Parts Production
SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe Bar Feeder High Efficiency Turning Machine for Automotive Parts Production
SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe Bar Feeder High Efficiency Turning Machine for Automotive Parts Production
SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe Bar Feeder High Efficiency Turning Machine for Automotive Parts Production
SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe Bar Feeder High Efficiency Turning Machine for Automotive Parts Production
SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe Bar Feeder High Efficiency Turning Machine for Automotive Parts Production
Specifications
MOQ :
1 Set
Max Cutting Diameter :
380 mm
Z-Axis Travel :
560 mm
Bar Feeder :
Optional
Spindle Hole Diameter :
80 mm
Rated Spindle Torque :
136 N.m
Z-Axis Rapid Traverse :
30 m/min
Model Number :
HTC40Q
Spindle Nose :
A2-8
Standard Chuck Size :
8 inch
X-Axis Travel :
200 mm
Packaging Details :
Vacuum-packed with anti-rust oil, wrapped in PE film, fixed in export-grade fumigation-free plywood case with reinforced steel frame for heavy machinery
Payment Terms :
T/T,L/C at sight
Front Bearing Inner Diameter :
120 mm
Main Motor Power (Cont/30min) :
11 kW
Max Bar Diameter :
50 mm
Spindle Max Torque :
245 N.m
CNC Control System :
GSK25Ti (FANUC/Siemens Optional)
Tool Turret :
12-Station Horizontal Servo Turret
Certification :
CE ISO9001 ISO14001
Tailstock Taper :
MT-5
Brand Name :
SMTCL
X-Axis Rapid Traverse :
30 m/min
Place of Origin :
Liaoning, China
Center Height :
100 mm
Max Cutting Length :
500 mm
Supply Ability :
20 Sets per Month
Max Swing Diameter over Bed :
560 mm
Tailstock Travel :
450 mm
Delivery Time :
35-45 working days after deposit
Spindle Speed Range :
4000 r/min
Machine Weight :
4200 kg
Overall Dimensions (L×W×H) :
2750×1890×1900 mm
Description
SMTCL HTC40Q Heavy Duty Horizontal CNC Lathe

A2-8 Spindle • 10" Chuck • 80mm Bar Capacity • 11 kW Motor • Mass Production Ready

✅ CE & ISO Certified
