LUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC Retro
LUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC Retro
LUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC Retro
LUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC Retro
LUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC Retro
LUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC Retro
LUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC Retro
LUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC Retro
Specifications
Model Number :
S400MN
Detection Center Distance :
400mm
Certification :
CE RoHS ISO
Temperature coefficient :
0.03%F.S./°C
Brand Name :
Luoshida
product name :
laser displacement sensor
MOQ :
5
Delivery Time :
5-8 work days
Max input current :
50mA
Response time :
Selectable among 1.5ms / 5ms / 10ms
Payment Terms :
L/C, D/A, D/P, T/T
Residual voltage :
≤1.5V (@input current ≤50mA)
Price :
Negotiable
Leakage current :
≤0.1mA
Supply Ability :
3000PCS per month
Voltage analog output :
Output range 0-5V, output impedance = 100Ω
Place of Origin :
Guangdong, China
Power supply voltage :
12-24VDC ±10%
Packaging Details :
Normal standard: individual package with labels and outside is normal brown box.
Description
Parameter Item Detailed Specification
Brand LOUSHIDA
Temperature characteristics 0.03%F.S./°C
Light source Red semiconductor laser, Class 2, max output 1mW, emission wavelength 655nm
Power supply voltage 12-24VDC ±10%, ripple P-P ≤10%
Current consumption Below 40mA at 24VDC supply; below 60mA at 12VDC supply
Control output NPN open collector transistor
Max input current: 50mA
Max applicable voltage: ≤30V DC
Residual voltage ≤1.5V (input ≤50mA)
Leakage current ≤0.1mA
Light-on / light-off output modes are selectable
Short-circuit protection Built-in auto-reset protection
Analog voltage output 0-5V output range, output impedance 100Ω
Analog current output 4-20mA output range, output impedance ≤300Ω
Response time Optional: 1.5ms / 5ms / 10ms
External trigger input NPN/PNP contactless input, effective trigger voltage: 0~+1.2V DC, input impedance 10KΩ
Protection standard IP67 (IEC)
Degree of contamination Grade 2
Operating temperature -10°C~+40°C (condensation and frosting forbidden); Storage temperature: -20°C~+60°C
Operating humidity 35%-85%RH; Storage humidity: 35%-85%RH
Operating illumination Keep humidity within 35%-85%RH both in working and standby states
Max operating altitude Below 2000m
Cable 2m 5-core cable, conductor diameter per core: 0.15mm
Shell material Aluminum casting main housing, acrylic front cover plate
Weight Approx 35g excluding cables; approx 85g with cables fitted
Certification Compliant with EMC Directive


LUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC Retro

Luoshida Sensor (Dongguan) Co., Ltd.

Founded in 2012, Luoshida is a high-tech enterprise dedicated to the R&D, production, sales and service of sensors. Its core products cover a wide range of types, including inductive/capacitive proximity sensors, laser displacement sensors, through-beam/diffuse-reflective photoelectric sensors, fiber optical sensors, and color mark sensors, which are widely applied in industrial automation, smart manufacturing and electronic equipment.

All products are developed and produced in line with IEC standards. They have passed strict tests (EMC, IP, vibration impact, high-low temperature) and obtained EU CE certification and ROHS compliance.
With a team of experienced technicians, Luoshida adheres to the concept of "people-oriented, integrity, quality first, customer first". It provides customers with international-standard products, fast technical support and customized solutions.
Looking forward, Luoshida will continue to focus on technological progress, contributing to global industrial intelligent upgrading.


LUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC RetroLUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC RetroLUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC RetroLUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC RetroLUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC RetroLUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC RetroLUOSHIDA S400MN Laser Displacement Sensor 30-400mm High Precision Distance Measurement NPN Dual Output IP67 12-24V DC Retro

FAQ

Relevant information about the service :

Shipping ways :
Our normal shipping way is internation express, such as DHL,FEDEX, TNT and so on;
When the gross weight is over 45kg, air trnasportation is also a good way for the customers to save some cost;
Sea transportation is also can be considered, but only appointed agent accetpable.

Payment term and delivery time :
1. Generaly speaking, 30% deposit in advance, balance paid before the shipping;
2. Sometimes the paypal payment method is also ok if the total amount is less than 500USD, such as sample fee;
3. Delivery time:
The sensors will be shipped out in 3 days when we receive the payment if we have stocks;
If no stocks, the delivery time will be 7-10days when we received the PO or deposit.

After-sales services :
1. The warranty period is 12 months
2. If we send the wrong parts to you, free replacement will be available
3. As for the installation of the parts. if you have any questions, please do not hesitate to contact us at any time.
