650nm Rectangles Grid DOE Laser Module Adjustable Brightness
650nm Rectangles Grid DOE Laser Module Adjustable Brightness
650nm Rectangles Grid DOE Laser Module Adjustable Brightness
650nm Rectangles Grid DOE Laser Module Adjustable Brightness
650nm Rectangles Grid DOE Laser Module Adjustable Brightness
650nm Rectangles Grid DOE Laser Module Adjustable Brightness
650nm Rectangles Grid DOE Laser Module Adjustable Brightness
650nm Rectangles Grid DOE Laser Module Adjustable Brightness
Specifications
Brand Name :
xinland
Model Number :
DOE Laser Module
Certification :
CE
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiated
Payment Terms :
T/T, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50000pcs per months
Delivery Time :
5-8 work days
Packaging Details :
1pc carton
Lens Angle :
26.1°
Number of Grids :
20*20=400
Laser Style :
Line
Light Source :
Red/Green/Blue
Wavelength :
450nm/520nm/650nm
Output Power :
50mw/100mw Customizable
Line Length :
1.2 Meters
Configure :
Imported laser diodes
Description

26.1° 20×20=400 Rectangles Grid Laser with Imported Laser DiodeS Adjustable Brightness

Product Details:
Wavelength Output Power Voltage(V) Electric Current Size
650nm 100mw DC 2.8-5.2V <500mA Φ16x70mm
520nm 50mw DC 2.8-5.2V <500mA Φ16x70mm
450nm 100mw DC 2.8-5.2V <500mA Φ16x70mm

Light Spot Details:

Lens angle: 26.1°
Lens angle in X direction: 26.1°
At 50 cm, the length in the X direction is 23.2 cm (a single small grid is 1.16 cm long in the X direction)
At 100 cm, the length in the X direction is 46.4 cm (a single small grid is 2.32 cm long in the X direction)
Y-direction lens angle: 8.5°
At 50 cm, the Y direction is 7.4 cm long (a single small grid is 0.37 cm long in the Y direction)
At 100 cm, the length in the Y direction is 14.8 cm (a single small grid is 0.74 cm long in the Y direction)
Wavelength, Output Power, Voltage and Size Customizable
Light Spot:
650nm Rectangles Grid DOE Laser Module Adjustable Brightness
650nm Rectangles Grid DOE Laser Module Adjustable Brightness
650nm Rectangles Grid DOE Laser Module Adjustable Brightness

Warranty:

we offer one year limited warranty for our products. Damage due to misuse, Ill treatment and unauthorized modifications will beyond our warranty.

Payment Method:

PayPal ( PayPal fee should be afforded at buyer's side), Bank Transfer, Western Union, and Money Gram.

Shipping Method:

DHL/FEDEX/UPS/EMS/TNT Express service; Post Service
