Specifications
Brand Name :
XINHONG
Model Number :
XH-3015L
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
FOB 12000 USD-18000USD
Payment Terms :
T/T
Supply Ability :
4000SETS/YEAR
Delivery Time :
30-55 working days
Packaging Details :
Container
Resolution Accuracy :
< 0.01mm
Reduction Gears :
Alpha Germany
Cnc Or Not :
Yes
Cutting Accuracy :
±0.01mm
Transmission :
Belt transmission
Laser Output Control :
0-100% set by software
Cnc :
yes
Driver :
Yako driver
Max. Cutting Speed :
40m/min
Color :
Customizable
Application :
Industrial Metal Cutting
Laser Source Brand :
Raycus
Laser Head :
Raytools auto focus BM110
Dimensions :
4200*2250*1840mm
Power Supply :
220V/50HZ, 110V/60HZ
Working Temperature :
0-35℃
Machine Weight :
1800kg
Working Area :
3080mm*1530*100mm
Controller System :
Raytools XC3000S
Beam and Gantry :
Aviation aluminum
Water Chiller :
1500W hanli
Air Conditioner :
Included
Description

Stainless Steel Carbon Steel Aluminum Copper/Brass CNC Metal Sheet Fiber Laser Cutting Machine

Advantages of Fiber Laser Cutting Machines over Traditional Cutting Machines

Fiber laser cutting machines offer a range of significant advantages over traditional cutting technologies, making them a preferred choice for modern metal processing industries:
1. Higher Precision and Cutting Quality
Fiber lasers produce a highly focused and stable laser beam, resulting in cleaner edges, minimal burring, and finer detail. This is especially beneficial for intricate patterns and precision components.
2. Faster Cutting Speeds
Compared to plasma or flame cutting, fiber lasers operate at much higher speeds, particularly when cutting thin to medium-thickness metals such as stainless steel or carbon steel. This dramatically increases productivity.
3. Lower Operating Costs
Fiber lasers are more energy-efficient and require less maintenance than CO₂ lasers or mechanical cutters. With no need for gas consumables (like plasma or flame cutting), operational expenses are significantly reduced.
4. Non-contact, Minimal Deformation
As a non-contact thermal process, fiber laser cutting minimizes mechanical stress and heat distortion on the material, preserving the integrity of thin or delicate workpieces.
5. Wide Material Compatibility
Fiber lasers can cut a wide range of metals including stainless steel, carbon steel, aluminum, brass, copper, and more — materials that are often difficult to cut with conventional methods.
6. Automation and Integration
Modern fiber laser systems support CNC integration, automatic loading/unloading, nesting software, and real-time monitoring, greatly enhancing efficiency and reducing human error.
7. Compact and Safe Design
Fiber laser machines typically feature a compact footprint and can be fully enclosed for safe operation, reducing noise, dust, and radiation exposure compared to open-cutting methods.
8. Longer Service Life
Fiber laser sources have longer lifespans (often over 100,000 hours) and offer stable performance over time, ensuring long-term reliability.


1 Model XH-3015L XH-4020L XH-6025L XH-8025L
2 Cutting Working Area 3000*1500mm 4000*2000mm 6000*2500mm 8000*2500mm
3 Power 1500w/2000w/3000w/6000w/12000W
4 Laser Source Brand Raycus/MAX with CE
5 Laser Head Raytools auto focus BM110
6 Control System Raytools XC3000S
7

Reducer

Japan Shimpo/France Motoreducer
8

Electronic Components

Schneider
9

Guide Rail

PEK
10

Grinding Rack

LEITESEN
11

Air Conditioner

Included
12

Machine Size

4200*2250*1840mm
13

Total Power

16.78KW


Stainless Steel Carbon Steel Aluminum Copper / Brass CNC Metal Sheet Fiber Laser Cutting Machine

Stainless Steel Carbon Steel Aluminum Copper / Brass CNC Metal Sheet Fiber Laser Cutting Machine

Stainless Steel Carbon Steel Aluminum Copper / Brass CNC Metal Sheet Fiber Laser Cutting Machine
