CNC Metal Fiber Laser Cutter 1000W 1500W 2000W 3000W 4000W 6000W Laser Cutting Machine For Carbon Stainless/Aluminum Steel / Metal/ Tube / Pipe/Plate
CNC Metal Fiber Laser Cutter 1000W 1500W 2000W 3000W 4000W 6000W Laser Cutting Machine For Carbon Stainless/Aluminum Steel / Metal/ Tube / Pipe/Plate
CNC Metal Fiber Laser Cutter 1000W 1500W 2000W 3000W 4000W 6000W Laser Cutting Machine For Carbon Stainless/Aluminum Steel / Metal/ Tube / Pipe/Plate
CNC Metal Fiber Laser Cutter 1000W 1500W 2000W 3000W 4000W 6000W Laser Cutting Machine For Carbon Stainless/Aluminum Steel / Metal/ Tube / Pipe/Plate
Specifications
Brand Name :
XINHONG
Model Number :
XH-3015L
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
FOB 12000 USD-18000USD
Payment Terms :
T/T
Supply Ability :
4000SETS/YEAR
Delivery Time :
30-55 working days
Packaging Details :
Container
Resolution Accuracy :
< 0.01mm
Reduction Gears :
Alpha Germany
Cnc Or Not :
Yes
Cutting Accuracy :
±0.01mm
Transmission :
Belt transmission
Laser Output Control :
0-100% set by software
Cnc :
yes
Driver :
Yako driver
Max. Cutting Speed :
40m/min
Color :
Customizable
Application :
Industrial Metal Cutting
Laser Source Brand :
Raycus
Laser Head :
Raytools auto focus BM110
Dimensions :
4200*2250*1840mm
Power Supply :
220V/50HZ, 110V/60HZ
Working Temperature :
0-35℃
Machine Weight :
1800kg
Working Area :
3080mm*1530*100mm
Controller System :
Raytools XC3000S
Beam and Gantry :
Aviation aluminum
Water Chiller :
1500W hanli
Air Conditioner :
Included
Description

CNC Metal Fiber Laser Cutter 1000W 1500W 2000W 3000W 4000W 6000W Laser Cutting Machine for Carbon Stainless/Aluminum Steel / Metal/ Tube / Pipe/Plate

  • The XINHONG Fiber Laser Cutting Machine is a well-developed product that meets advanced domestic standards.

  • This series is ideal for applications in the metal processing industry.

  • Following aging and annealing treatment, the machine bed is constructed as an integrated honeycomb carbon structure, offering exceptional strength and stability.

  • The beam is made from aerospace-grade or cast aluminum, ensuring high cutting precision.

  • With its high-speed operation, the machine significantly enhances processing efficiency.

1 Model XH-3015L XH-4020L XH-6025L XH-8025L
2 Cutting Working Area 3000*1500mm 4000*2000mm 6000*2500mm 8000*2500mm
3 Power 1500w/2000w/3000w/6000w/12000W
4 Laser Source Brand Raycus/MAX with CE
5 Laser Head Raytools auto focus BM110
6 Control System Raytools XC3000S
7

Reducer

 Japan Shimpo/France Motoreducer
8

Electronic Components

 Schneider
9

Guide Rail

 PEK
10

Grinding Rack

 LEITESEN
11

Air Conditioner

 Included
12

Machine Size

 4200*2250*1840mm
13

Total Power

 16.78KW


CNC Metal Fiber Laser Cutter 1000W 1500W 2000W 3000W 4000W 6000W Laser Cutting Machine For Carbon Stainless/Aluminum Steel / Metal/ Tube / Pipe/Plate

CNC Metal Fiber Laser Cutter 1000W 1500W 2000W 3000W 4000W 6000W Laser Cutting Machine For Carbon Stainless/Aluminum Steel / Metal/ Tube / Pipe/Plate

CNC Metal Fiber Laser Cutter 1000W 1500W 2000W 3000W 4000W 6000W Laser Cutting Machine For Carbon Stainless/Aluminum Steel / Metal/ Tube / Pipe/Plate
