3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
3W / 5W 3D Jewelry Laser Marking Machine For Metal Non Metal Pattern Depth Engraving
Specifications
Brand Name :
JPTECH
Certification :
CE/FCC
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
50 sets/month
Delivery Time :
5-7 days
Packaging Details :
wood carton
Laser wavelength :
355nm±1nm
After-sales Service :
Online support, Video technical support
After Warranty Service :
Video technical support, Online support
computer :
With the computer
ambient temperature :
10 to 35 ℃, humidity is < 80%
Function :
Metal Glass Crystal Engraving Marking
Power supply :
AC220V +10% / 50HZ
Description

3D Jewelry Gold And Silver Metal Non Metal Laser Marking Machine Three Dimensional Pattern Depth Engraving

Laser wavelength 355nm±1nm
ambient temperature 10 to 35 ℃, humidity is < 80%
storage temperature ‘-10-40℃, humidity <90%
Laser Power 3W /5W
Applicable Material Glass Acrylic Ceramic Plastic Metal
Power supply 220V/50HZ
Single Pulse Energy (uJ) ~100uJ@30kHz/~160uJ@30kHz
Pulse Width (ns) ~15ns@30kHz
Repitition Rate 20-500kHz
Pulse Stability <3% rms
Long Term Stability <±3%
Polarization Ratio Horizontal; >100:1
Beam Diameter Beam Diameter
Beam Circularity Beam Diameter
Beam Circularity >90%
Spatial Mode TEM00, M2 <1.3
Warm-up Time <15 minutes from cold start
Electrical Requirement DC12V,350W
Cooling System Water-Cooled
Water Temperature (laser inlet) 25℃
