10w 30w 40w 355nm Femtosecond Fiber Laser
10w 30w 40w 355nm Femtosecond Fiber Laser
10w 30w 40w 355nm Femtosecond Fiber Laser
10w 30w 40w 355nm Femtosecond Fiber Laser
10w 30w 40w 355nm Femtosecond Fiber Laser
10w 30w 40w 355nm Femtosecond Fiber Laser
Specifications
Place of Origin :
china
MOQ :
1set
Price :
negotiated
Payment Terms :
T/T, Western Union
Supply Ability :
1000set
Delivery Time :
3-5 work days
Packaging Details :
carton
Control software :
EZCAD
Cooling mode :
Air Cooling,Water Cooling
Application :
Laser Marking
Laser wavelength :
355nm
Warranty :
1 Year,2 Years
Condition :
New
Description

Huaray Laser (A invested company of JCZ) is developing and manufacturing reliable femtosecond ultrafast laser HR-Femto series of industrial-level fiber femtosecond lasers. They are categorized into the HR-Femto-10 (10 μJ), HR-Femto-50 (50 μJ), and HR-Femto-50HE (80 μJ) series, which are verified, highly reliable, and can be used 24/7. Laser pulse widths of <350 fs or <350 fs to 5 ps are adjustable. Greenlight wavelengths can be output by using a harmonic generator (SHG).

The HR-Femto-50 series of industrial femtosecond lasers are proven, highly reliable, and are designed for 24/7 operation. The laser supports >60 W power at 1035 nm wavelength, >80 μJ single pulse energy, adjustable pulse widths from

Main Features:
- Up to 60 W average power
- Single pulse energy up to 80 μJ
- - 1 Hz - 1 MHz Adjustable Repeat Frequency
- Supports multiple Burst Mode combinations
- Includes pulse selector for on-demand pulse splitting
- Rugged, industrialized one-piece design
- Optional SHG module to support green light output

Application Field:

  • - Drilling and cutting of hard and brittle materials
  • Glass Welding
  • Micro fabrication of metal materials
  • Composite film material processing
  • New Energy Materials Processing
  • Processing and handling of polymers
  • Medical device manufacturing
  • Fiber Optic Grating Writing
  • Glass Laser Engraving

10w 30w 40w 355nm Femtosecond Fiber Laser

SPECIFICATIONS HR-Femto-IR-50-40 HR-Femto-IR-80-60 HR-Femto-GN-25-20 HR-Femto-GN-30-24
Center Wavelength 1035 nm 1035 nm 517nm 517nm
Average Power 40 W 60 W 20 W 24 W
Pulse Energy 50 μJ @ 800 kHz 80 μJ @ 750 kHz 25 μJ @ 800 kHz 30 μJ @750 kHz
Pulse Duration
Burst Energy 200 μJ 320 μJ 100 μJ 120 μJ
Peak Power >140 MW >220 MW >70 MW >110 MW
Repetition Rate Single shot to 1 MHz Single shot to 1 MHz Single shot to 1 MHz Single shot to 1 MHz
Beam Quality M2≤1.3 M2≤1.3 M2≤1.3 M2≤1.3
Beam Divergence
Beam Circularity ≥90% ≥90% ≥90% ≥90%
Beam Diameter 3 ±1 mm, 1/e2 3 ±1 mm, 1/e2 3 ±1 mm, 1/e2 4 ±2 mm, 1/e2
Polarization State Linear Linear Linear Linear
Pulse Stability <2% RMS <2% RMS <2% RMS <2% RMS
Power Stability <2% RMS <2% RMS <2% RMS <2% RMS
Operating Temp 10 to 30 °C 10 to 30 °C 10 to 30 °C 10 to 30 °C
