High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
Specifications
Brand Name :
JCZ
Model Number :
GO5-Green-10-D
Place of Origin :
Beijing, China
MOQ :
1 set
Price :
USD 1000-1200/set
Payment Terms :
T/T, Western Union
Supply Ability :
10000 set/month
Delivery Time :
1 day
Packaging Details :
carton
laser :
UV
wave lenght :
532nm
speed :
5000
contain :
scan head + power + connect
spot size :
10mm
Power :
±15V ,5A
Description

High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25


Quick Detail:

  • laser-based scanners used on fiber laser machine for laser marking and laser engraving.High precision, quality, provide after-sales service

High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25



Description:

Condition

New

Laser Type

Green

CNC or Not

Not

Cooling Mode

Air Cooling

Control Software

EZCAD

Graphic Format Supported

AI, BMP, DST, DWG, DXF, DXP, LAS, PLT

Working Accuracy

0.005

Place of Origin

Beijing, China (Mainland)

Brand Name

JCZ

Model Number

GO5-Green-10-D

After-sales Service Provided

Overseas service center available

color

grey

Work stable

One year warranty , during this time ,we repair the product free.

Lifetime after-sales services

Professional team to provide after-sales technical support

Professional team Software Develop ,can custom the special software

10 years for laser marking /engraving control system


Applications:

  • Laser Marking ,
  • laser engraving

High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
Specifications:

The optical hole diameter

10mm

Corresponding time step

The deflection Angle of 1%

0.4ms

The deflection Angle of 10%

1.2ms

Speed

Marking speed

5000mm/s

Positioning speed

100000mm/s

Temperature drift(more than 8 hours)

<0.3mrad

Interface protocol

XY2-100 Standard

Optical performance

Scanning angle

±0.35 rad

Gain error

＜5 mrad

Zero offset

＜5 mrad

Working temperature

25℃ ± 10℃

Power

±15V/5A


High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25
Competitive Advantage:

  • Cheap ,
  • high speed,
  • work stable ,
  • good quality
  • zero drift,
  • smaller size

Ship way

High Speed Industry Laser Scanning Head 532nm Green Laser 10mm With DB 25 DHL TNT UPS FEDEX EMS and so on
