Specifications
Place of Origin :
Guangdong, China
Packaging Details :
Plywood box
Price :
USD1000-1500
Brand Name :
DAPENG
Model Number :
YLP-20
Certification :
CE, ISO
MOQ :
1 set
Payment Terms :
T/T
Supply Ability :
150 sets per month
Delivery Time :
5-10 days
Application :
Laser Marking
Working Accuracy :
0.01mm
Graphic Format Supported :
AI, BMP, DXF, HPGL
Laser Type :
Fiber Laser
Condition :
New
CNC or Not :
Yes
Cooling Mode :
Air Cooling
Control Software :
Linux
Laser Source Brand :
MAX
Control System Brand :
Linux
Weight (KG) :
7 KG
Key Selling Points :
Easy to Operate
Warranty :
1 years
Marking Area :
100mm*100mm
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
2 years
Core Components :
Laser Source
Mode of Operation :
Pulsed
Configuration :
hand-held
Feature :
Automated Loading
Product name :
Handheld laser marking machine
Advantage :
Portable-type and high-accuracy
Wavelength :
1064nm
Source :
110V/220V AC
Package size :
525cm*423cm*310cm
Marking range :
70mm*70mm 100mm*100mm(optional)
Output Power :
20W/30W
Description
DAPENG 20W 30W handheld laser Mini Laser Marking Portable Laser Engraving Machines
Product Description
Item
Value
Product name
Handheld laser marking machine
Advantage
Portable-type and high-accuracy
Source
110V/220V AC. lithium cell(216wh)
Marking range
70mm*70mm 100mm*100mm(optional)
Output Power
20W/25W/30W
Applied materials
Variours metals,Plastic,Glass,Wood,Leather,Aluminum products,Paper
Package
Laser, marking card, handheld galvanometer, battery, focusing ring, instruction manual, packaging cotton, packaging paper box,
electrical accessories, plastic casing mold opening
Set position square type
Red light set position right coke

Features:

1. Excellent light quality:
Comparing with traditional solid laser marking machine, angle of divergence is only 1/4 of diode pump laser device. It is especially suitable for precision marking.
2. Low usage cost:
Photo electric conversion efficiency max is 30%, whole machine power consumption is less than 500W, it is the 1/10 of laser pump lamp marking machine. It greatly saves the cost in power consumption.
3. Free maintenance & long service life:
Using laser diode as the source of pump, full sealing light path design, its average no-failure operation is over 100 thousand hours.
