JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes
JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes
JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes
JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes
JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes
JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes
Specifications
Model Number :
JAB-40
Inner diameter of through-hole :
40mm
Payment Terms :
D/P, L/C, D/A, T/T, Western Union, MoneyGram
Clamping repeatability accuracy :
≤ 0.005mm
Installation flange outer diameter :
168mm
Price :
2000-2800 USD
Standard clamping range :
φ 6- φ 38mm circular tube
Supply Ability :
500 sets per month
Standard through-hole diameter :
40mm
Certification :
Provided
MOQ :
1
Delivery Time :
10 days
Total thickness :
118mm
Maximum outer diameter :
187mm
Net weight of the whole machine :
42kg
Packaging Details :
Plywood Box
Brand Name :
Lingman
Flange fixing hole :
4 × M8 countersunk mounting hole
Place of Origin :
Changzhou, Jiangsu, China
Description

JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes

JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes

1. Descripition
Model: JAB-40 integrated gear transmission rotary pneumatic cylinder clamp chuck (special for laser cutting pipe tail clamp)
Purpose: Fiber laser pipe cutting machine is used to rotate and clamp the driven tail, and is matched with the front main chuck to achieve synchronous rotation and cutting of the pipe throughout the entire process
Structure: JAB40 high-speed air compressor rotary chuck+gear transmission base+lifting adjustment bracket complete assembly

2. Clamping and through-hole specifications

Standard through-hole diameter: 40mm
Compatible with tube clamp specifications: JAB40 elastic tube clamp (dual-use for external clamping of round pipes/internal expansion of pipes)
Standard clamping range: φ 6- φ 38mm circular tube
Clamping method: Forward push bidirectional cylinder, forced loosening to prevent material jamming and sticking
Clamping repeatability accuracy: ≤ 0.005mm, thin-walled tubes are not easily deformed during clamping

3. Dimensions and external parameters (JAB40 body)

Maximum outer diameter: 187mm
Installation flange outer diameter: 168mm
Total thickness: 118mm
Inner diameter of through-hole: 40mm
Flange fixing hole: 4 × M8 countersunk mounting hole
Supporting transmission gear: standard modulus helical gear, which can mesh synchronously with the rotating gear of the main engine for transmission


4. Production Line

JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes

JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes

5. Certification

JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes

6. Application

JAB-40 Integrated Gear Transmission Rotary Pneumatic Cylinder Clamp Chuck with 40mm Through-Hole and ≤ 0.005mm Accuracy for φ 6-φ 38mm Tubes
