Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
Specifications
MOQ :
1 Set
Delivery Time :
10-15 work days
Bracing range :
20-180mm
Packaging Details :
Wood carton
Price :
USD 500 set
Maximun clamping :
32.9KN
Max. bracing force :
18.5KN
Application :
Milling Machine
Model Number :
LM160HAL
Allowable pressure :
0.4-0.8Mpa
Payment Terms :
T/T, L/C
Jaw stroke/diameter :
3.7mm
Clamping range :
2-170mm
Supply Ability :
500 set per month
Model :
LM160HAL
Certification :
Provided
Place of Origin :
China
Usage :
Pipe Clamp
Brand Name :
LINGMAN
Weight :
18.6KG
Description

Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder

1. Description

Our company is a professional manufacturer of producing chucks for CNC lathe and laser cutting machine.

Various kinds of laser chucks are provided. We provide laser chucks for many well-known laser cutting machines at home and abroad. Our products are also welcomed by many customers.

The products can be widely used in pipe cutting systems such as special laser pipe cutting machines.

2. Performance Parameters

Model LM160HAL
Jaw stroke/diameter 3.7mm
Max. clamping force 32.9KN
Max. bracing force 18.5KN
Clamping range 2-170mm
Bracing range 20-180mm
Allowable pressure 0.4-0.8Mpa
Weight 18.6KG
Application Milling Machine
Usage Pipe Clamp



Note: above numbers are standard parameters. We can also design products according to clients' special requirements.
​3. Dimensions
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder

Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder

4. Advantages

a. Full stroke design
b. Wide range of applications, diversification of processing profiles
c. High repetitive positioning accuracy
d. Low maintenance cost, long service life

e. Multiple configurations are available

e.1 Solid or hollow

e.2 Comb-type or mortise-groove type claws

5. Our Service

a. We are the direct factory with good price and fast lead time.
b. Professional design team work with you.
c. Professional QC team to guarantee the high quality.
d. Providing OEM & ODM service.


6. Production Line
Vertical Hollow Chuck Pneumatic Chuck LM160HAL Milling Machine Pipe Clamp Cnc 3 Jaw 125mm Chuck Built-in Power Cylinder
