Higher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kw
Higher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kw
Higher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kw
Higher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kw
Higher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kw
Higher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kw
Higher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kw
Higher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kw
Specifications
Brand Name :
Lanphan
Model Number :
HF-10
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 set
Price :
$11299
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 Sets per Month
Delivery Time :
10-12 days
Packaging Details :
Wooden Box or Customized Packing
Name :
Large Spray Dryer
Total Power :
28kw/380v
Mean drying time (s) :
1-1.5
Temperature control accuracy (℃) :
±1
Minimum feeding amount (ml/h) :
200
Maximum feeding capacity (ml/h) :
10000
Description

Higher Efficiency Milk Powder Making Stainless Steel Milk Spray Drying Machine

Product Parameter

Product Name Large Spray Dryer
Inlet air temperature control (℃) 180～250
Air outlet temperature control (℃) 80～90
Centrifugal nozzle speed 22000rpm
Water evaporation (ml/h) 10kg/H
Maximum feeding capacity (ml/h) 10000
Minimum feeding amount (ml/h) 200
Mode of feed Peristaltic pump regulation
Temperature control accuracy (℃) ±1
Mean drying time (s) 1～1.5
Total Power 28kw/380v
Stainless steel drying tower size (mm) Diameter1400 height 2700
Product Dimension(mm) 2500x1500x2600
Package Dimension(mm) 2600x1600x2800

Product Application


Various fields where the production of a free powder sample is required.
LPG-10L has successfully processed samples in the following areas: Beverage, Flavours and colourings, Milk and egg products, Plant and vegetable extracts, Pharmaceuticals, Synthetics Heat sensitive materials, Plastics polymers and resins, Perfumes, Blood, Ceramics and superconductors Biochemicals, Dyestuffs, Soaps and detergents, Foodstuffs, Adehesives, Oxides, Textiles, Bones, Teeth and tooth amalgam and many others.

Spray drying machine operating step:

  • Start red total power supply.
  • LCD screen: Chinese and English.
  • Start fan.
  • Start heating set 150-220 (general common temperature).
  • Outlet temperature reach over 80 degree.
  • Start atomizer.
  • Outlet temperature between 85-100.
  • Start peristaltic pump feeding material, peristaltic pump set 20. (please note: before start peristaltic pump, please ensure drying tower and collection flask is dryer, without water or liquid ).
  • Outlet temperature reach over 100 degrees, peristaltic pump speed set 30.40.50.60.70.80.90.100.
  • Outlet temperature is controlled by the set air inlet temperature and peristaltic pump material feeding quantity.

Higher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kwHigher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kwHigher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kwHigher Efficiency Centrifugal Spray Dryer Milk Powder Stainless Steel 28kw
